14. Advanced Topics¶

14.1. Adding support for your MIDI/HID Controller¶

With several dozens of DJ controllers supported out-of-the-box, Mixxx gives you comprehensive hardware control for your DJ mixes, see Using MIDI/HID Controllers.

Support for additional devices can be added to Mixxx by creating a new preset file. This file tells Mixxx how to translate, or map, MIDI/HID messages from a controller into commands that Mixxx understands.

You can download and share custom controller presets in the Mixxx User customizations forums.

Controller Wizard¶

By far, the easiest way to create a new MIDI preset is by using the Controller Wizard.

Connect your controller(s) to your computer
Start Mixxx
Go to Preferences ‣ Controllers
Select your device from the list of available devices on the left, and the right pane will change
Activate the Enabled checkbox
Click on Learning Wizard to open the selection dialog
Click any control in the Mixxx GUI
Alternatively, click the Choose Control button and choose one from the selection list
Push Learn and then move a control or push a button on your controller to map it. You can also move a control without pushing the Learn button if you are learning many controls.
If you are learning a button, just push it once. If you are learning a knob or a slider, try to move it throughout its range.
After Mixxx detects the control, you may click Learn Another or you can click on another button in the Mixxx GUI to learn another control.
When you are finished mapping controls, click Done

There are also some advanced options in the Midi Wizard you may need to use:

Soft Takeover: Use this option for knobs or sliders to avoid sudden jumps in when the knob in the GUI doesn’t match the physical knob. If you select this option, you won’t be able to perform super-fast motions as easily. (Recommended off)
Invert: Use this option for controls that you want to work backwards from how they were detected.
Switch Mode: Use this option on controllers that have controls that act like switches and emit one value on the first press, and a different value on the next press. (Think an actual hardware toggle switch, or a button that lights up on the first press and turns off on the second press).
Jog Wheel / Select Knob: Use this for knobs that don’t have a beginning or an end, but spin continuously.

The Controller wizard saves the new preset to the following file paths:

Linux: /home/<username>/.mixxx/controllers
macOS: /Users/<username>/Library/Application\ Support/Mixxx/controllers
Windows: %LOCALAPPDATA%\Mixxx\controllers

You can then modify the XML file it creates (or any of the ones that ship with Mixxx) if you’d like to fine-tune it or add more presets. For more information, go to https://github.com/mixxxdj/mixxx/wiki/MIDI-Controller-Mapping-File-Format.

The Controller Wizard works only for MIDI devices. Currently you can’t map modifier (shift) keys and platter rotations. Use MIDI Scripting instead.

MIDI Scripting¶

In order to support the advanced features of many MIDI/HID controllers, Mixxx offers what we call MIDI Scripting.

It enables MIDI controls to be mapped to QtScript (aka Javascript/EMCAScript) functions stored in function library files, freeing Mixxx from a one-to-one MIDI mapping ideology. These user-created functions can then do anything desired with the MIDI event such as have a single controller button simultaneously affect two or more Mixxx properties (“controls”), adjust incoming control values to work better with Mixxx (scratching), display a complex LED sequence, or even send messages to text displays on the controller.

For more information, go to https://github.com/mixxxdj/mixxx/wiki/Midi-Scripting and https://github.com/mixxxdj/mixxx/wiki/hid_mapping_format.

Mixxx Controls¶

Nearly every knob, button, or fader you see in Mixxx’s interface is controllable via Mixxx’s “control” system. The control system allows skins, MIDI controllers, HID controllers and keyboards to control Mixxx via a single interface.

A control is identified by a “group” (which is used for grouping associated controls) and a “key” (the name of the individual control).

For example, the volume fader for Deck 1 is identified by the group [Channel1] and key volume. Similarly, the volume fader for Sampler 1 is identified by the group [Sampler1] and key volume.

The group is used to collect all the controls that affect one component of Mixxx into one collection. Some groups have a high overlap of controls in common (e.g. samplers, decks, and the preview deck all share the same control keys).

In addition to controlling Mixxx, the control system can be used to inspect Mixxx’s state. For example, the sample rate of the track loaded in Deck 1 can be accessed via the [Channel1],track_samplerate control. You can read the [Channel3],play control to determine whether Deck 3 is playing.

The default value range is 0.0 to 1.0, unless otherwise noted. Binary means that it is either ‘ON’ (non-zero) or ‘OFF’ (zero).

İpucu

Discovering Controls used in Skins

You can view the control connected to any part of a skin by running Mixxx with the --developer command line option and hovering your mouse cursor over part of the skin. If no tooltip appears, enable tooltips for the Library and Skin in Options ‣ Preferences ‣ Interface.

İpucu

Changing any control from the GUI in Developer Mode

When running Mixxx in Developer Mode (with the --developer command line option), you can view and manually set the state of any control in Mixxx by going to Developer ‣ Developer Tools.

Ayrıca bakınız

See Control Index for a full list.

ControlPotMeter controls¶

The following extensions add some features to ControlPotMeter controls (volume, crossfader, …). Use in conjunction with [ChannelN], [SamplerN], [Master], … groups.

Control Suffix	Description
`_up`	Increases the value, e.g. `[ChannelN],rate_perm_up` sets the speed one step higher (4 % default)
`_down`	Decreases the value, sets the speed one step lower (4 % default)
`_up_small`	Increases the value by smaller step, sets the speed one small step higher (1 % default)
`_down_small`	Decreases the value by smaller step, sets the speed one small step lower (1 % default)
`_set_one`	Sets the value to 1.0, sets the channel volume to full
`_set_minus_one`	Sets the value to -1.0, sets the channel volume to zero
`_set_default`	Sets the control to its default, return to default waveform zoom level
`_set_zero`	Sets the value to 0.0, put the crossfader in the middle again
`_toggle`	Sets the value to 0.0 if the value was > 0.0, and to 1.0 if the value was 0.0, will cut off/on a track while you’re playing
`_minus_toggle`	Sets the value to -1.0 if the value was > -1.0, and to 1.0 if the value was -1.0, can tilt the crossfader from left to right

These controls can be used in JavaScript files like this:

// This won't work:
engine.setValue(group, "pitch_up_small", 1.0);

// Use this instead:
script.triggerControl(group, "pitch_up_small", 50);

To use *_toggle the respective shortcut for scripts is:

script.toggleControl(group, "keylock_toggle", 100);

The `[Master]` group¶

The [Master] group generally corresponds to controls that affect the mixing engine. This will bear some similarity to what you will find on a DJ mixer (e.g. crossfader controls, headphone cueing controls, etc.).

[Master]audio_latency_usage¶

Reflects fraction of latency, given by the audio buffer size, spend for audio processing inside Mixxx. At value near 25 % there is a high risk of buffer underflows

This is a ControlPotMeter control.

Range: 0 .. 25 %
Feedback: latency meter

2.0.0 sürümünde geldi.

[Master]audio_latency_overload¶

Indicates a buffer under or over-flow. Resets after 500 ms

This is a ControlPotMeter control.

Range: binary
Feedback: Overload indicator

2.0.0 sürümünde geldi.

[Master]audio_latency_overload_count¶

Counts buffer over and under-flows. Max one per 500 ms

Range: 0 .. n
Feedback: Counter in hardware preferences

2.0.0 sürümünde geldi.

[Master]balance¶

Adjusts the left/right channel balance on the Master output.

This is a ControlPotMeter control.

Range: -1.0..1.0
Feedback: Center Balance knob

[Master]booth_enabled¶

Indicates whether a Booth output is configured in the Sound Hardware Preferences.

Range: binary
Feedback: Booth gain knob shown or hidden

2.1.0 sürümünde geldi.

[Master]booth_gain¶

Adjusts the gain of the Booth output.

This is a ControlPotMeter control.

Range: 0.0…1.0…5.0
Feedback: Booth gain knob

2.1.0 sürümünde geldi.

[Master]crossfader¶

Adjusts the crossfader between players/decks (-1.0 is all the way left).

This is a ControlPotMeter control.

Range: -1.0..1.0
Feedback: Crossfader slider

[Master]crossfader_down¶

Moves the crossfader left by 1/10th.

Range: binary
Feedback: Crossfader slider

[Master]crossfader_down_small¶

Moves the crossfader left by 1/100th.

Range: binary
Feedback: Crossfader slider

1.10.0 sürümünde geldi.

[Master]crossfader_up¶

Moves the crossfader right by 1/10th.

Range: binary
Feedback: Crossfader slider

[Master]crossfader_up_small¶

Moves the crossfader right by 1/100th.

Range: binary
Feedback: Crossfader slider

1.10.0 sürümünde geldi.

[Master]duckStrength¶

Microphone ducking strength

This is a ControlPotMeter control.

Range: 0.0..1.0
Feedback: Strength knob

2.0.0 sürümünde geldi.

[Master]enabled¶

Indicator that the master mix is processed.

Range: binary
Feedback: None

2.0.0 sürümünde geldi.

[Master]gain¶

Adjusts the gain for the master output as well as recording and broadcasting signal.

This is a ControlPotMeter control.

Range: 0.0..1.0..5.0
Feedback: Master volume knob

2.0.0 sürümünde geldi.

[Master]headEnabled¶

Indicator that the headphone mix is processed.

Range: binary
Feedback: None

2.0.0 sürümünde geldi.

[Master]headGain¶

Adjusts the headphone output gain.

This is a ControlPotMeter control.

Range: 0.0..1.0..5.0
Feedback: Headphone volume knob

2.0.0 sürümünde geldi.

[Master]headMix¶

Adjusts the cue/main mix in the headphone output.

This is a ControlPotMeter control.

Range: default
Feedback: Pre/Main knob

[Master]headSplit¶

Splits headphone stereo cueing into right (master mono) and left (PFL mono).

Range: binary
Feedback: Split Cue button

2.0.0 sürümünde geldi.

[Master]latency¶

Latency setting (sound buffer size) in milliseconds (default 64).

Range: >=0 (absolute value)
Feedback: Latency slider in the prefs

[Master]maximize_library¶

Toggle maximized view of library.

Range: binary
Feedback: Toggle maximized view of library

2.0.0 sürümünde geldi.

[Master]num_decks¶

The number of decks currently enabled.

Range: integer
Feedback: None

1.9.0 sürümünde geldi.

[Master]num_effectsavailable¶

The number of available effects that can be selected in an effect slot.

Range: integer, read-only
Feedback: None

2.1.0 sürümünde geldi.

[Master]num_samplers¶

The number of samplers currently enabled.

Range: integer
Feedback: None

1.9.0 sürümünde geldi.

[Master]num_preview_decks¶

The number of preview decks currently enabled.

Range: integer
Feedback: None

1.11.0 sürümünde geldi.

[Master]PeakIndicator¶

Indicates when the signal is clipping (too loud for the hardware and is being distorted) (composite).

This is a ControlPotMeter control.

Range: binary
Feedback: Clip light (mono)

[Master]PeakIndicatorL¶

Indicates when the signal is clipping (too loud for the hardware and is being distorted) for the left channel.

This is a ControlPotMeter control.

Range: binary
Feedback: Clip light (left)

[Master]PeakIndicatorR¶

Indicates when the signal is clipping (too loud for the hardware and is being distorted) for the right channel.

This is a ControlPotMeter control.

Range: binary
Feedback: Clip light (right)

[Master]samplerate¶

The current output sample rate (default: 44100 Hz).

Range: absolute value (in Hz)
Feedback: None

[Master]talkoverDucking¶

Toggle microphone ducking mode (OFF, AUTO, MANUAL)

Range: FIXME
Feedback: Ducking mode button

2.0.0 sürümünde geldi.

[Master]VuMeter¶

Outputs the current instantaneous master volume (composite).

This is a ControlPotMeter control.

Range: default
Feedback: Master meter (mono)

[Master]VuMeterL¶

Outputs the current instantaneous master volume for the left channel.

This is a ControlPotMeter control.

Range: default
Feedback: Master meter L

[Master]VuMeterR¶

Outputs the current instantaneous master volume for the right channel.

This is a ControlPotMeter control.

Range: default
Feedback: Master meter R

[Master]headVolume¶

Adjust headphone volume.

Range: 0.0..1.0..5.0
Feedback: Headphone Gain knob

2.0.0 sürümünden beri kullanım dışı: Use [Master],headGain instead.

[Master]volume¶

Adjust master volume.

Range: 0.0..1.0..5.0
Feedback: Master Gain knob

2.0.0 sürümünden beri kullanım dışı: Use [Master],gain instead.

Decks, Preview Decks and Samplers¶

Each deck in Mixxx corresponds to a [ChannelN] group. Whenever you see [ChannelN], think “Deck N”. N can range from 1 to the number of active decks in Mixxx.

Preview decks and Sample decks (“samplers”) in Mixxx are identical to regular decks, they simply have a different purpose (previewing tracks or playing samples, respectively). Any control listed above for [ChannelN] will work for a samplers and preview decks, just replace [ChannelN] with [PreviewDeckN] or [SamplerN].

Ayrıca bakınız

There are some additional global controls for samplers.

[ChannelN]back¶

[PreviewDeckN]back¶

[SamplerN]back¶

Fast rewind (REW)

Range: binary
Feedback: < button

[ChannelN]beat_active¶

[PreviewDeckN]beat_active¶

[SamplerN]beat_active¶

Indicates whether the player is currently positioned within 50 milliseconds of a beat or not.

Range: binary
Feedback: None

1.10.0 sürümünde geldi.

[ChannelN]beatjump¶

[PreviewDeckN]beatjump¶

[SamplerN]beatjump¶

Jump forward by X beats (positive) or backward by X beats (negative). If a loop is active, the loop is moved by X beats.

Range: real number
Feedback: Player jumps forward or backward by X beats.

2.0.0 sürümünde geldi.

[ChannelN]beatjump_size¶

[PreviewDeckN]beatjump_size¶

[SamplerN]beatjump_size¶

Set the number of beats to jump with beatjump_forward/beatjump_backward.

Range: positive real number
Feedback: Beatjump size spinbox

2.1.0 sürümünde geldi.

[ChannelN]beatjump_forward¶

[PreviewDeckN]beatjump_forward¶

[SamplerN]beatjump_forward¶

Jump forward by beatjump_size. If a loop is active, the loop is moved forward by X beats.

Range: binary
Feedback: Player jumps forward by beatjump_size.

2.1.0 sürümünde geldi.

[ChannelN]beatjump_backward¶

[PreviewDeckN]beatjump_backward¶

[SamplerN]beatjump_backward¶

Jump backward by beatjump_size. If a loop is active, the loop is moved backward by X beats.

Range: binary
Feedback: Player jumps backward by beatjump_size.

2.1.0 sürümünde geldi.

[ChannelN]beatjump_X_forward¶

[PreviewDeckN]beatjump_X_forward¶

[SamplerN]beatjump_X_forward¶

Jump forward by X beats. A control exists for X = 0.03125, 0.0625, 0.125, 0.25, 0.5, 1, 2, 4, 8, 16, 32, 64. If a loop is active, the loop is moved forward by X betas.

Range: binary
Feedback: Player jumps forward by X beats.

2.0.0 sürümünde geldi.

[ChannelN]beatjump_X_backward¶

[PreviewDeckN]beatjump_X_backward¶

[SamplerN]beatjump_X_backward¶

Jump backward by X beats. A control exists for X = 0.03125, 0.0625, 0.125, 0.25, 0.5, 1, 2, 4, 8, 16, 32, 64. If a loop is active, the loop is moved backward by X beats.

Range: binary
Feedback: Player jumps backward by X beats.

2.0.0 sürümünde geldi.

[ChannelN]beatloop_activate¶

[PreviewDeckN]beatloop_activate¶

[SamplerN]beatloop_activate¶

Set a loop that is beatloop_size beats long and enables the loop

Range: binary
Feedback: A loop is shown over beatloop_size beats

2.1.0 sürümünde geldi.

[ChannelN]beatloop_X_activate¶

[PreviewDeckN]beatloop_X_activate¶

[SamplerN]beatloop_X_activate¶

Activates a loop over X beats. A control exists for X = 0.03125, 0.0625, 0.125, 0.25, 0.5, 1, 2, 4, 8, 16, 32, 64

Range: binary
Feedback: A loop is shown over X beats.

1.10.0 sürümünde geldi.

[ChannelN]beatloop_size¶

[PreviewDeckN]beatloop_size¶

[SamplerN]beatloop_size¶

Set the length of the loop in beats that will get set with beatloop_activate and beatlooproll_activate. Changing this will resize an existing loop if the length of the loop matches beatloop_size.

Range: positive real number
Feedback: Beatloop size spinbox and possibly loop section on waveform

2.1.0 sürümünde geldi.

[ChannelN]beatloop_X_toggle¶

[PreviewDeckN]beatloop_X_toggle¶

[SamplerN]beatloop_X_toggle¶

Toggles a loop over X beats. A control exists for X = 0.03125, 0.0625, 0.125, 0.25, 0.5, 1, 2, 4, 8, 16, 32, 64

Range: binary
Feedback: A loop is shown over X beats.

1.10.0 sürümünde geldi.

[ChannelN]beatloop_X_enabled¶

[PreviewDeckN]beatloop_X_enabled¶

[SamplerN]beatloop_X_enabled¶

1 if beatloop X is enabled, 0 if not.

Range: binary
Feedback: Beatloop X button in skin is lit.

1.10.0 sürümünde geldi.

[ChannelN]beatlooproll_activate¶

[PreviewDeckN]beatlooproll_activate¶

[SamplerN]beatlooproll_activate¶

Activates a rolling loop over beatloop_size beats. Once disabled, playback will resume where the track would have been if it had not entered the loop.

Range: binary
Feedback: A loop overlay is shown over beatloop_size beats on waveform.

2.1.0 sürümünde geldi.

[ChannelN]beatlooproll_X_activate¶

[PreviewDeckN]beatlooproll_X_activate¶

[SamplerN]beatlooproll_X_activate¶

Activates a rolling loop over X beats. Once disabled, playback will resume where the track would have been if it had not entered the loop. A control exists for X = 0.03125, 0.0625, 0.125, 0.25, 0.5, 1, 2, 4, 8, 16, 32, 64

Range: binary
Feedback: Beatloop X button in skin is lit. A loop overlay is shown over X beats on waveform.

1.11.0 sürümünde geldi.

[ChannelN]beats_adjust_faster¶

[PreviewDeckN]beats_adjust_faster¶

[SamplerN]beats_adjust_faster¶

Adjust the average BPM up by +0.01

Range: binary
Feedback: The beatgrid lines move closer to each other.

2.0.0 sürümünde geldi.

[ChannelN]beats_adjust_slower¶

[PreviewDeckN]beats_adjust_slower¶

[SamplerN]beats_adjust_slower¶

Adjust the average BPM down by -0.01.

Range: binary
Feedback: The beatgrid lines move further apart from each other.

2.0.0 sürümünde geldi.

[ChannelN]beats_translate_curpos¶

[PreviewDeckN]beats_translate_curpos¶

[SamplerN]beats_translate_curpos¶

Adjust beatgrid so closest beat is aligned with the current playposition.

Range: binary
Feedback: The beatgrid moves to align with current playposition.

1.10.0 sürümünde geldi.

[ChannelN]beats_translate_match_alignment¶

[PreviewDeckN]beats_translate_match_alignment¶

[SamplerN]beats_translate_match_alignment¶

Adjust beatgrid to match another playing deck.

Range: binary
Feedback: Instead of syncing the beatgrid to the current playposition, sync the beatgrid so the nearest beat lines up with the other track’s nearest beat.

2.0.0 sürümünde geldi.

[ChannelN]beats_translate_earlier¶

[PreviewDeckN]beats_translate_earlier¶

[SamplerN]beats_translate_earlier¶

Move beatgrid to an earlier position.

Range: binary
Feedback: The beatgrid moves left by a small amount.

2.0.0 sürümünde geldi.

[ChannelN]beats_translate_later¶

[PreviewDeckN]beats_translate_later¶

[SamplerN]beats_translate_later¶

Move beatgrid to a later position.

Range: binary
Feedback: The beatgrid moves right by a small amount.

2.0.0 sürümünde geldi.

[ChannelN]beatsync¶

[PreviewDeckN]beatsync¶

[SamplerN]beatsync¶

Syncs the tempo and phase (depending on quantize) to that of the other track (if BPM is detected on both).

range

binary

feedback

The Sync button flashes and the tempo slider snaps to the appropriate value.

1.10.0 sürümünde değişti.

[ChannelN]beatsync_phase¶

[PreviewDeckN]beatsync_phase¶

[SamplerN]beatsync_phase¶

Syncs the phase to that of the other track (if BPM is detected on both).

Range: binary
Feedback: The Sync button flashes and the tempo slider snap to the appropriate value.

1.10.0 sürümünde geldi.

[ChannelN]beatsync_tempo¶

[PreviewDeckN]beatsync_tempo¶

[SamplerN]beatsync_tempo¶

Syncs the tempo to that of the other track (if BPM is detected on both).

Range: binary
Feedback: The Sync button flashes and the tempo slider snaps to the appropriate value.

1.10.0 sürümünde geldi.

[ChannelN]bpm¶

[PreviewDeckN]bpm¶

[SamplerN]bpm¶

Reflects the perceived (rate-adjusted) BPM of the loaded file.

This is a ControlPotMeter control.

Range: real-valued
Feedback: BPM value display

1.10.0 sürümünde değişti.

[ChannelN]bpm_tap¶

[PreviewDeckN]bpm_tap¶

[SamplerN]bpm_tap¶

When tapped repeatedly, adjusts the tempo of the channel to match the tapped BPM.

Range: binary
Feedback: BPM value display (playback speed doesn’t change)

1.9.2 sürümünde geldi.

[ChannelN]CloneFromDeck¶

[PreviewDeckN]CloneFromDeck¶

[SamplerN]CloneFromDeck¶

Clone the given deck number, copying the play state, position, rate, and key. If 0 or a negative number is given, Mixxx will attempt to select the first playing deck as the source for the clone.

Range: integer between 1 and [Master],num_decks (inclusive)
Feedback: The channel will start playing at the rate and position of the source deck.

2.3.0 sürümünde geldi.

[ChannelN]CloneFromSampler¶

[PreviewDeckN]CloneFromSampler¶

[SamplerN]CloneFromSampler¶

Clone the given sampler number, copying the play state, position, rate, and key.

Range: integer between 1 and [Master],num_samplers (inclusive)
Feedback: The channel will start playing at the rate and position of the source deck.

2.3.0 sürümünde geldi.

[ChannelN]cue_default¶

[PreviewDeckN]cue_default¶

[SamplerN]cue_default¶

In CDJ mode, when playing, returns to the cue point and pauses. If stopped, sets a cue point at the current location. If stopped and at a cue point, plays from that point until released (set to 0.)

Range: binary
Feedback: Cue button

[ChannelN]cue_gotoandplay¶

[PreviewDeckN]cue_gotoandplay¶

[SamplerN]cue_gotoandplay¶

If the cue point is set, seeks the player to it and starts playback.

Range: binary
Feedback: Player may change position and start playing.

1.11.0 sürümünde geldi.

[ChannelN]cue_gotoandstop¶

[PreviewDeckN]cue_gotoandstop¶

[SamplerN]cue_gotoandstop¶

If the cue point is set, seeks the player to it and stops.

Range: binary
Feedback: Player may change position.

1.11.0 sürümünde geldi.

[ChannelN]cue_indicator¶

[PreviewDeckN]cue_indicator¶

[SamplerN]cue_indicator¶

Provides information to be bound to the Cue Button e.g. blinking when next press will move the cue point

Range: binary
Feedback: Cue button

2.0.0 sürümünde geldi.

[ChannelN]cue_cdj¶

[PreviewDeckN]cue_cdj¶

[SamplerN]cue_cdj¶

Represents a Cue button that is always in CDJ mode.

Range: binary
Feedback: None

1.10.0 sürümünde geldi.

[ChannelN]cue_play¶

[PreviewDeckN]cue_play¶

[SamplerN]cue_play¶

Go to cue point and play after release (CUP button behavior). If stopped, sets a cue point at the current location.

Range: binary
Feedback: None

2.1.0 sürümünde geldi.

[ChannelN]cue_point¶

[PreviewDeckN]cue_point¶

[SamplerN]cue_point¶

The current position of the cue point in samples

Range: absolute value
Feedback: Cue point marker

[ChannelN]cue_preview¶

[PreviewDeckN]cue_preview¶

[SamplerN]cue_preview¶

Plays from the current cue point

Range: binary
Feedback: Cue button lights and waveform moves

[ChannelN]cue_set¶

[PreviewDeckN]cue_set¶

[SamplerN]cue_set¶

Sets a cue point at the current location

Range: binary
Feedback: Cue mark appears on the waveform

[ChannelN]cue_simple¶

[PreviewDeckN]cue_simple¶

[SamplerN]cue_simple¶

If the player is not playing, set the cue point at the current location otherwise seek to the cue point.

Range: binary
Feedback: Cue button

[ChannelN]duration¶

[PreviewDeckN]duration¶

[SamplerN]duration¶

Outputs the length of the current song in seconds

Range: absolute value
Feedback: None

[ChannelN]eject¶

[PreviewDeckN]eject¶

[SamplerN]eject¶

Eject currently loaded track

Range: binary
Feedback: Eject button is lit. Be sure to set back to 0 with scripts so the button does not stay lit.

1.9.0 sürümünde geldi.

[ChannelN]end¶

[PreviewDeckN]end¶

[SamplerN]end¶

Jump to end of track

Range: binary
Feedback: Track jumps to end

[ChannelN]end_of_track¶

[PreviewDeckN]end_of_track¶

[SamplerN]end_of_track¶

Switches to 1 if the play position is within the end range defined in Preferences ‣ Waveforms ‣ End of track warning.

Range: binary, read-only
Feedback: Waveform and Overview widgets show a flashing border

[ChannelN]file_bpm¶

[PreviewDeckN]file_bpm¶

[SamplerN]file_bpm¶

The detected BPM of the loaded track.

Range: positive value, read-only
Feedback: None

[ChannelN]file_key¶

[PreviewDeckN]file_key¶

[SamplerN]file_key¶

The detected key of the loaded track.

Range: ?, read-only
Feedback: None

2.0.0 sürümünde geldi.

[ChannelN]fwd¶

[PreviewDeckN]fwd¶

[SamplerN]fwd¶

Fast forward (FF)

Range: binary
Feedback: > button

[ChannelN]hotcue_X_activate¶

[PreviewDeckN]hotcue_X_activate¶

[SamplerN]hotcue_X_activate¶

If hotcue X is not set, this sets a hotcue at the current play position and saves it as hotcue X of type “Hotcue”. In case a loop is currently enabled (i.e. if [ChannelN],loop_enabled is set to 1), the loop will be saved as hotcue X instead and hotcue_X_type will be set to “Loop”.

If hotcue X has been set as a regular cue point, the player seeks to the saved play position.

If hotcue_X_type is “Loop”, looping will be enabled and the loop controls (e.g. loop_start_position, :mixxx:coref:`loop_end_position <[ChannelN],loop_end_position> and beatloop_size <[ChannelN],beatloop_size>`) will be set accordingly. Just like reloop_toogle, the player seeks back to the loop start when the current play position is behind the loop, and enabled without a seek when it is in front of or inside the loop. This allows a loop catching behavior on one hand and a jump back when the loop has been exit by just triggering this control.

Setting the control to 1 when the track is currently not playing (i.e. play is set to 0) will start hotcue previewing. After resetting the control to 0, playback will usually be stopped and the player will seek to the hotcue position. If play is to 1 while previewing is active, the playback will continue and no seek occurs.

Range: binary
Feedback: Player may change position. Hotcue X marker may change on waveform.

1.8.0 sürümünde geldi.

2.4.0 sürümünde değişti: Added support for saved loops.

[ChannelN]hotcue_X_activatecue¶
[PreviewDeckN]hotcue_X_activatecue¶
[SamplerN]hotcue_X_activatecue¶: Identical to hotcue_X_activate, but this always sets a regular cue point, regardless of whether a loop is enabled or not. This control can be used for controllers that have dedicated hotcue/saved loop pad modes.

2.4.0 sürümünde geldi.

[ChannelN]hotcue_X_activateloop¶
[PreviewDeckN]hotcue_X_activateloop¶
[SamplerN]hotcue_X_activateloop¶: Identical to hotcue_X_activate, but this always sets a saved loop, regardless of whether a loop is enabled or not. If no loop is available, this sets and enables a beat loop of of beatloop_size. This control can be used for controllers that have dedicated hotcue/saved loop pad modes.

2.4.0 sürümünde geldi.

[ChannelN]hotcue_X_cueloop¶

[PreviewDeckN]hotcue_X_cueloop¶

[SamplerN]hotcue_X_cueloop¶

Enables or disables a loop from the position of hotcue X. If X is a saved loop, that loop will be used, otherwise it will set a beatloop of beatloop_size from the cue position. In case the hotcue is not set, this control will set a regular cue point at the current position and start a beatloop.

This control can be used to map the primary action of the “Cue Loop” performance pad mode on Serato-style controllers.

2.4.0 sürümünde geldi.

[ChannelN]hotcue_X_clear¶

[PreviewDeckN]hotcue_X_clear¶

[SamplerN]hotcue_X_clear¶

If hotcue X is set, clears its hotcue status.

Range: binary
Feedback: Hotcue X marker changes on waveform.

1.8.0 sürümünde geldi.

[ChannelN]hotcue_X_color¶

[PreviewDeckN]hotcue_X_color¶

[SamplerN]hotcue_X_color¶

Color of hotcue X or -1 if the hotcue is not set.

Range: 3-Byte RGB color code (or -1)
Feedback: Color of Hotcue X button and waveform marker changes.

2.3.0 sürümünde geldi.

[ChannelN]hotcue_X_enabled¶

[PreviewDeckN]hotcue_X_enabled¶

[SamplerN]hotcue_X_enabled¶

Indicates if hotcue slot X is set, active or empty.

Range: read-only ===== =================================== Value Meaning ===== =================================== 0 Hotcue X is not set 1 Hotcue X is set 2 Hotcue X is active (saved loop is enabled or hotcue is previewing) ===== ===================================

1.8.0 sürümünde geldi.

2.4.0 sürümünde değişti: Added support for “active” state.

2.4.0 sürümünden beri kullanım dışı: Use [ChannelN],hotcue_X_status instead.

[ChannelN]hotcue_X_status¶

[PreviewDeckN]hotcue_X_status¶

[SamplerN]hotcue_X_status¶

Indicates if hotcue slot X is set, active or empty.

Range: read-only ===== =================================== Value Meaning ===== =================================== 0 Hotcue X is not set 1 Hotcue X is set 2 Hotcue X is active (saved loop is enabled or hotcue is previewing) ===== ===================================

2.4.0 sürümünde geldi: Replaces the deprecated [ChannelN],hotcue_X_enabled.

[ChannelN]hotcue_X_type¶

[PreviewDeckN]hotcue_X_type¶

[SamplerN]hotcue_X_type¶

Indicates the type of the hotcue in hotcue slot X.

Range: read-only ===== =================================== Value Type ===== =================================== 0 Invalid/Not Set 1 Hotcue 4 Saved Loop ===== ===================================

2.4.0 sürümünde geldi.

[ChannelN]hotcue_X_goto¶

[PreviewDeckN]hotcue_X_goto¶

[SamplerN]hotcue_X_goto¶

If hotcue X is set, seeks the player to hotcue X’s position.

Range: binary
Feedback: Player may change position.

1.8.0 sürümünde geldi.

[ChannelN]hotcue_X_gotoandplay¶

[PreviewDeckN]hotcue_X_gotoandplay¶

[SamplerN]hotcue_X_gotoandplay¶

If hotcue X is set, seeks the player to hotcue X’s position and starts playback.

Range: binary
Feedback: Player may change position.

1.11.0 sürümünde geldi.

[ChannelN]hotcue_X_gotoandloop¶

[PreviewDeckN]hotcue_X_gotoandloop¶

[SamplerN]hotcue_X_gotoandloop¶

If hotcue X is set, seeks the player to hotcue X’s position, starts playback and looping. If the hotcue is a saved loop, the loop is enabled, otherwise a beatloop of beatloop_size is set from the hotcue’s position.

This control can be used to map the secondary action of the “Cue Loop” performance pad mode on Serato-style controllers.

Range: binary
Feedback: Player may change position and looping is enabled.

2.4.0 sürümünde geldi.

[ChannelN]hotcue_X_gotoandstop¶

[PreviewDeckN]hotcue_X_gotoandstop¶

[SamplerN]hotcue_X_gotoandstop¶

If hotcue X is set, seeks the player to hotcue X’s position and stops.

Range: binary
Feedback: Player may change position.

1.8.0 sürümünde geldi.

[ChannelN]hotcue_X_position¶

[PreviewDeckN]hotcue_X_position¶

[SamplerN]hotcue_X_position¶

The position of hotcue X in samples, -1 if not set.

Range: positive integer
Feedback: Hotcue X marker changes on waveform.

1.8.0 sürümünde geldi.

[ChannelN]hotcue_X_set¶

[PreviewDeckN]hotcue_X_set¶

[SamplerN]hotcue_X_set¶

Set a hotcue at the current play position and saves it as hotcue X of type “Hotcue”. In case a loop is currently enabled (i.e. if [ChannelN],loop_enabled is set to 1), the loop will be saved as hotcue X instead and hotcue_X_type will be set to “Loop”.

Range: binary
Feedback: Hotcue X marker changes on waveform.

1.8.0 sürümünde geldi.

2.4.0 sürümünde değişti.

[ChannelN]hotcue_X_setcue¶

[PreviewDeckN]hotcue_X_setcue¶

[SamplerN]hotcue_X_setcue¶

Identical to hotcue_X_setcue, but this always sets a regular cue point (i.e. hotcue_X_type “Hotcue”), regardless of whether a loop is enabled or not.

This control can be used for controllers that have dedicated hotcue/saved loop pad modes.

2.4.0 sürümünde geldi.

[ChannelN]hotcue_X_setloop¶
[PreviewDeckN]hotcue_X_setloop¶
[SamplerN]hotcue_X_setloop¶: Identical to hotcue_X_setloop, but this always saves a loop (i.e. hotcue_X_type “Loop”), regardless of whether a loop is enabled or not. If no loop is available, this sets and enables a beat loop of of beatloop_size. This control can be used for controllers that have dedicated hotcue/saved loop pad modes.

2.4.0 sürümünde geldi.

[ChannelN]hotcue_focus¶

[PreviewDeckN]hotcue_focus¶

[SamplerN]hotcue_focus¶

Contains the number of the most recently used hotcue (or -1 if no hotcue was used).

Range: positive integer (or -1)
Feedback: None

2.3.0 sürümünde geldi.

[ChannelN]hotcue_focus_color_prev¶

[PreviewDeckN]hotcue_focus_color_prev¶

[SamplerN]hotcue_focus_color_prev¶

If there is a focused hotcue, sets its color to the previous color in the palette.

Range: binary
Feedback: Color of focused hotcue button and waveform marker changes.

2.3.0 sürümünde geldi.

[ChannelN]hotcue_focus_color_next¶

[PreviewDeckN]hotcue_focus_color_next¶

[SamplerN]hotcue_focus_color_next¶

If there is a focused hotcue, sets its color to the next color in the palette.

Range: binary
Feedback: Color of focused hotcue button and waveform marker changes.

2.3.0 sürümünde geldi.

[ChannelN]intro_end_activate¶

[PreviewDeckN]intro_end_activate¶

[SamplerN]intro_end_activate¶

If the intro end cue is set, seeks the player to the intro end position. If the intro end is not set, sets the intro end to the current play position.

Range: binary
Feedback: Player may change position. Intro end marker may change on waveform.

2.3.0 sürümünde geldi.

[ChannelN]intro_end_clear¶

[PreviewDeckN]intro_end_clear¶

[SamplerN]intro_end_clear¶

If the intro end cue is set, clears its status.

Range: binary
Feedback: Intro end marker changes on waveform.

2.3.0 sürümünde geldi.

[ChannelN]intro_end_enabled¶

[PreviewDeckN]intro_end_enabled¶

[SamplerN]intro_end_enabled¶

1 if intro end cue is set, (position is not -1), 0 otherwise.

Range: binary, read-only
Feedback: Intro end button lights up.

2.3.0 sürümünde geldi.

[ChannelN]intro_end_position¶

[PreviewDeckN]intro_end_position¶

[SamplerN]intro_end_position¶

The position of the intro end in samples, -1 if not set.

Range: positive integer
Feedback: Intro end marker changes on waveform.

2.3.0 sürümünde geldi.

[ChannelN]intro_end_set¶

[PreviewDeckN]intro_end_set¶

[SamplerN]intro_end_set¶

Set intro end to the current play position. If intro end was previously set, it is moved to the new position.

Range: binary
Feedback: Intro end marker changes on waveform.

2.3.0 sürümünde geldi.

[ChannelN]intro_start_activate¶

[PreviewDeckN]intro_start_activate¶

[SamplerN]intro_start_activate¶

If the intro start cue is set, seeks the player to the intro start position. If the intro start is not set, sets the intro start to the current play position.

Range: binary
Feedback: Player may change position. Intro start marker may change on waveform.

2.3.0 sürümünde geldi.

[ChannelN]intro_start_clear¶

[PreviewDeckN]intro_start_clear¶

[SamplerN]intro_start_clear¶

If the intro start cue is set, clears its status.

Range: binary
Feedback: Intro start marker changes on waveform.

2.3.0 sürümünde geldi.

[ChannelN]intro_start_enabled¶

[PreviewDeckN]intro_start_enabled¶

[SamplerN]intro_start_enabled¶

1 if intro start cue is set, (position is not -1), 0 otherwise.

Range: binary, read-only
Feedback: Intro start button lights up.

2.3.0 sürümünde geldi.

[ChannelN]intro_start_position¶

[PreviewDeckN]intro_start_position¶

[SamplerN]intro_start_position¶

The position of the intro start in samples, -1 if not set.

Range: positive integer
Feedback: Intro start marker changes on waveform.

2.3.0 sürümünde geldi.

[ChannelN]intro_start_set¶

[PreviewDeckN]intro_start_set¶

[SamplerN]intro_start_set¶

Set intro start to the current play position. If intro start was previously set, it is moved to the new position.

Range: binary
Feedback: Intro start marker changes on waveform.

2.3.0 sürümünde geldi.

[ChannelN]key¶

[PreviewDeckN]key¶

[SamplerN]key¶

Current key of the track

Range: real-valued

2.0.0 sürümünde geldi.

[ChannelN]keylock¶

[PreviewDeckN]keylock¶

[SamplerN]keylock¶

Enable key-lock for the specified deck (rate changes only affect tempo, not key)

Range: binary
Feedback: key-lock button activates

1.9.0 sürümünde geldi.

[ChannelN]LoadSelectedTrack¶

[PreviewDeckN]LoadSelectedTrack¶

[SamplerN]LoadSelectedTrack¶

Loads the currently highlighted track into the deck

Range: binary
Feedback: Track name & waveform change

[ChannelN]LoadSelectedTrackAndPlay¶

[PreviewDeckN]LoadSelectedTrackAndPlay¶

[SamplerN]LoadSelectedTrackAndPlay¶

Loads the currently highlighted track into the deck and starts playing

Range: binary
Feedback: Track name & waveform change & Play/pause button

1.11.0 sürümünde geldi.

[ChannelN]loop_double¶

[PreviewDeckN]loop_double¶

[SamplerN]loop_double¶

Doubles beatloop_size. If beatloop_size equals the size of the loop, the loop is resized.

If a saved loop is currently enabled, the modification is saved to the hotcue slot immediately.

Range: binary
Feedback: Beatloop size spinbox changes

1.10.0 sürümünde geldi.

2.1.0 sürümünde değişti.

2.4.0 sürümünde değişti: Added support for saved loops.

[ChannelN]loop_enabled¶

[PreviewDeckN]loop_enabled¶

[SamplerN]loop_enabled¶

Indicates whether or not a loop is enabled.

Range: binary
Feedback: Loop in waveform is active.

1.8.0 sürümünde geldi.

2.4.0 sürümünde değişti: Control is not longer read-only and can be used to enable/disable looping.

[ChannelN]loop_end_position¶

[PreviewDeckN]loop_end_position¶

[SamplerN]loop_end_position¶

The player loop-out position in samples, -1 if not set.

Range: positive integer
Feedback: Loop-out marker shows on waveform.

1.8.0 sürümünde geldi.

[ChannelN]loop_halve¶

[PreviewDeckN]loop_halve¶

[SamplerN]loop_halve¶

Halves beatloop_size. If beatloop_size equals the size of the loop, the loop is resized.

If a saved loop is currently enabled, the modification is saved to the hotcue slot immediately.

Range: binary
Feedback: Beatloop size spinbox changes

1.10.0 sürümünde geldi.

2.1.0 sürümünde değişti.

2.4.0 sürümünde değişti: Added support for saved loops.

[ChannelN]loop_in¶

[PreviewDeckN]loop_in¶

[SamplerN]loop_in¶

If loop is disabled, sets the player loop in position to the current play position. If loop is enabled, press and hold to move loop in position to the current play position. If quantize is enabled, beatloop_size will be updated to reflect the new loop size.

Range: binary
Feedback: Loop-in marker changes on waveform.

1.8.0 sürümünde geldi.

2.1.0 sürümünde değişti.

[ChannelN]loop_in_goto¶

[PreviewDeckN]loop_in_goto¶

[SamplerN]loop_in_goto¶

Seek to the loop in point.

Range: binary
Feedback: Waveform position jumps

2.1.0 sürümünde geldi.

[ChannelN]loop_out¶

[PreviewDeckN]loop_out¶

[SamplerN]loop_out¶

If loop is disabled, sets the player loop out position to the current play position. If loop is enabled, press and hold to move loop out position to the current play position. If quantize is enabled, beatloop_size will be updated to reflect the new loop size.

Range: binary
Feedback: Loop-out marker changes on waveform.

1.8.0 sürümünde geldi.

2.1.0 sürümünde değişti.

[ChannelN]loop_out_goto¶

[PreviewDeckN]loop_out_goto¶

[SamplerN]loop_out_goto¶

Seek to the loop out point.

Range: binary
Feedback: Waveform position jumps

2.1.0 sürümünde geldi.

[ChannelN]loop_move¶

[PreviewDeckN]loop_move¶

[SamplerN]loop_move¶

Move loop forward by X beats (positive) or backward by X beats (negative).

If a saved loop is currently enabled, the modification is saved to the hotcue slot immediately.

Range: real number
Feedback: Loop moves forward or backward by X beats.

2.0.0 sürümünde geldi.

2.4.0 sürümünde değişti: Added support for saved loops.

[ChannelN]loop_move_X_forward¶

[PreviewDeckN]loop_move_X_forward¶

[SamplerN]loop_move_X_forward¶

Moves the loop in and out points forward by X beats. A control exists for X = 0.03125, 0.0625, 0.125, 0.25, 0.5, 1, 2, 4, 8, 16, 32, 64

Range: binary
Feedback: Loop moves forward by X beats.

If a saved loop is currently enabled, the modification is saved to the hotcue slot immediately.

2.0.0 sürümünde geldi.

2.4.0 sürümünde değişti: Added support for saved loops.

[ChannelN]loop_move_X_backward¶

[PreviewDeckN]loop_move_X_backward¶

[SamplerN]loop_move_X_backward¶

Loop moves by X beats. A control exists for X = 0.03125, 0.0625, 0.125, 0.25, 0.5, 1, 2, 4, 8, 16, 32, 64

If a saved loop is currently enabled, the modification is saved to the hotcue slot immediately.

Range: binary
Feedback: Loop moves backward by X beats.

2.0.0 sürümünde geldi.

2.4.0 sürümünde değişti: Added support for saved loops.

[ChannelN]loop_scale¶

[PreviewDeckN]loop_scale¶

[SamplerN]loop_scale¶

Scale the loop length by the value scale is set to by moving the end marker. beatloop_size is not updated to reflect the change.

If a saved loop is currently enabled, the modification is saved to the hotcue slot immediately.

Range: 0.0 - infinity
Feedback: Loop length is scaled by given amount on waveform.

1.10.0 sürümünde geldi.

2.4.0 sürümünde değişti: Added support for saved loops.

[ChannelN]loop_start_position¶

[PreviewDeckN]loop_start_position¶

[SamplerN]loop_start_position¶

The player loop-in position in samples, -1 if not set.

Range: positive integer
Feedback: Loop-in marker changes on waveform.

1.8.0 sürümünde geldi.

[ChannelN]orientation¶

[PreviewDeckN]orientation¶

[SamplerN]orientation¶

Set channel orientation for the crossfader.

Range

Value	Meaning
0	Left side of crossfader
1	Center (not affected by crossfader)
2	Right side of crossfader

Feedback

None

1.9.0 sürümünde geldi.

[ChannelN]outro_end_activate¶

[PreviewDeckN]outro_end_activate¶

[SamplerN]outro_end_activate¶

If the outro end cue is set, seeks the player to the outro end position. If the outro end is not set, sets the outro end to the current play position.

Range: binary
Feedback: Player may change position. Outro end marker may change on waveform.

2.3.0 sürümünde geldi.

[ChannelN]outro_end_clear¶

[PreviewDeckN]outro_end_clear¶

[SamplerN]outro_end_clear¶

If the outro end cue is set, clears its status.

Range: binary
Feedback: Outro end marker changes on waveform.

2.3.0 sürümünde geldi.

[ChannelN]outro_end_enabled¶

[PreviewDeckN]outro_end_enabled¶

[SamplerN]outro_end_enabled¶

1 if outro end cue is set, (position is not -1), 0 otherwise.

Range: binary, read-only
Feedback: Outro end button lights up.

2.3.0 sürümünde geldi.

[ChannelN]outro_end_position¶

[PreviewDeckN]outro_end_position¶

[SamplerN]outro_end_position¶

The position of the outro end in samples, -1 if not set.

Range: positive integer
Feedback: Outro end marker changes on waveform.

2.3.0 sürümünde geldi.

[ChannelN]outro_end_set¶

[PreviewDeckN]outro_end_set¶

[SamplerN]outro_end_set¶

Set outro end to the current play position. If outro end was previously set, it is moved to the new position.

Range: binary
Feedback: Outro end marker changes on waveform.

2.3.0 sürümünde geldi.

[ChannelN]outro_start_activate¶

[PreviewDeckN]outro_start_activate¶

[SamplerN]outro_start_activate¶

If the outro start cue is set, seeks the player to the outro start position. If the outro start is not set, sets the outro start to the current play position.

Range: binary
Feedback: Player may change position. Outro start marker may change on waveform.

2.3.0 sürümünde geldi.

[ChannelN]outro_start_clear¶

[PreviewDeckN]outro_start_clear¶

[SamplerN]outro_start_clear¶

If the outro start cue is set, clears its status.

Range: binary
Feedback: Outro start marker changes on waveform.

2.3.0 sürümünde geldi.

[ChannelN]outro_start_enabled¶

[PreviewDeckN]outro_start_enabled¶

[SamplerN]outro_start_enabled¶

1 if outro start cue is set, (position is not -1), 0 otherwise.

Range: binary, read-only
Feedback: Outro start button lights up.

2.3.0 sürümünde geldi.

[ChannelN]outro_start_position¶

[PreviewDeckN]outro_start_position¶

[SamplerN]outro_start_position¶

The position of the outro start in samples, -1 if not set.

Range: positive integer
Feedback: Outro start marker changes on waveform.

2.3.0 sürümünde geldi.

[ChannelN]outro_start_set¶

[PreviewDeckN]outro_start_set¶

[SamplerN]outro_start_set¶

Set outro start to the current play position. If outro start was previously set, it is moved to the new position.

Range: binary
Feedback: Outro start marker changes on waveform.

2.3.0 sürümünde geldi.

[ChannelN]passthrough¶

[PreviewDeckN]passthrough¶

[SamplerN]passthrough¶

Connects the vinyl control input for vinyl control on that deck to the channel output. Allows to mix external media into DJ sets.

Range: binary
Feedback: Passthrough label in the waveform overview and passthrough button

2.0.0 sürümünde geldi.

[ChannelN]PeakIndicator¶

[PreviewDeckN]PeakIndicator¶

[SamplerN]PeakIndicator¶

Indicates when the signal is clipping (too loud for the hardware and is being distorted)

This is a ControlPotMeter control.

Range: binary
Feedback: Clip light

[ChannelN]PeakIndicatorL¶

[PreviewDeckN]PeakIndicatorL¶

[SamplerN]PeakIndicatorL¶

Indicates when the signal is clipping (too loud for the hardware and is being distorted) for the left channel

This is a ControlPotMeter control.

Range: binary
Feedback: Clip light (left)

2.0.0 sürümünde geldi.

[ChannelN]PeakIndicatorR¶

[PreviewDeckN]PeakIndicatorR¶

[SamplerN]PeakIndicatorR¶

Indicates when the signal is clipping (too loud for the hardware and is being distorted) for the right channel

This is a ControlPotMeter control.

Range: binary
Feedback: Clip light (right)

2.0.0 sürümünde geldi.

[ChannelN]pfl¶

[PreviewDeckN]pfl¶

[SamplerN]pfl¶

Toggles headphone cueing (PFL).

Range: binary
Feedback: Headphone button

[ChannelN]pitch¶

[PreviewDeckN]pitch¶

[SamplerN]pitch¶

The total adjustment to the track’s pitch, including changes from the rate slider if keylock is off as well as pitch_adjust.

Not

Do not map this to knobs or sliders on controllers; map pitch_adjust instead.

This is a ControlPotMeter control.

Range: -6.0..6.0
Feedback: Key display

2.0.0 sürümünde geldi.

[ChannelN]pitch_up¶

[PreviewDeckN]pitch_up¶

[SamplerN]pitch_up¶

Changes the track pitch up one half step, independent of the tempo.

Range: binary
Feedback: Key display

2.0.0 sürümünde geldi.

[ChannelN]pitch_down¶

[PreviewDeckN]pitch_down¶

[SamplerN]pitch_down¶

Changes the track pitch down one half step, independent of the tempo.

Range: binary
Feedback: Key display

2.0.0 sürümünde geldi.

[ChannelN]pitch_adjust¶

[PreviewDeckN]pitch_adjust¶

[SamplerN]pitch_adjust¶

Adjust the pitch in addition to the tempo slider pitch.

This is a ControlPotMeter control.

Range: -3.0..3.0
Feedback: Key display

2.0.0 sürümünde geldi.

[ChannelN]play¶

[PreviewDeckN]play¶

[SamplerN]play¶

Toggles playing or pausing the track.

Range: binary, 1.0 if track is playing or play command is adopted and track will be played after loading
Feedback: Play/pause button

[ChannelN]play_indicator¶

[PreviewDeckN]play_indicator¶

[SamplerN]play_indicator¶

Provides information to be bound with the a Play/Pause button e.g blinking when play is possible

Range: binary
Feedback: Play/pause button

2.0.0 sürümünde geldi.

[ChannelN]play_stutter¶

[PreviewDeckN]play_stutter¶

[SamplerN]play_stutter¶

A play button without pause. Pushing while playing, starts play at cue point again (Stutter).

Range: binary
Feedback: Play/Stutter button

2.0.0 sürümünde geldi.

[ChannelN]playposition¶

[PreviewDeckN]playposition¶

[SamplerN]playposition¶

Sets the absolute position in the track. The Range is -0.14 to 1.14 (0 = beginning -> Midi 14, 1 = end -> Midi 114)

This is a ControlPotMeter control.

Range: default
Feedback: Waveform

[ChannelN]pregain¶

[PreviewDeckN]pregain¶

[SamplerN]pregain¶

Adjusts the pre-fader gain of the track (to avoid clipping)

This is a ControlPotMeter control.

Range: 0.0..1.0..4.0
Feedback: GAIN knob

[ChannelN]quantize¶

[PreviewDeckN]quantize¶

[SamplerN]quantize¶

Aligns Hot-cues and Loop In & Out to the next beat from the current position.

Range: binary
Feedback: Hot-cues or Loop In/Out markers

1.10.0 sürümünde geldi.

[ChannelN]rate¶

[PreviewDeckN]rate¶

[SamplerN]rate¶

Speed control

This is a ControlPotMeter control.

Range: -1.0..1.0
Feedback: Speed slider

[ChannelN]rate_dir¶

[PreviewDeckN]rate_dir¶

[SamplerN]rate_dir¶

Indicates orientation of speed slider.

Range: -1 or 1

[ChannelN]rate_perm_down¶

[PreviewDeckN]rate_perm_down¶

[SamplerN]rate_perm_down¶

Sets the speed one step lower (4 % default) lower

Range: binary
Feedback: Perm down button & Speed slider

[ChannelN]rate_perm_down_small¶

[PreviewDeckN]rate_perm_down_small¶

[SamplerN]rate_perm_down_small¶

Sets the speed one small step lower (1 % default)

Range: binary
Feedback: Perm down button & Speed slider

[ChannelN]rate_perm_up¶

[PreviewDeckN]rate_perm_up¶

[SamplerN]rate_perm_up¶

Sets the speed one step higher (4 % default)

Range: binary
Feedback: Perm up button & Speed slider

[ChannelN]rate_perm_up_small¶

[PreviewDeckN]rate_perm_up_small¶

[SamplerN]rate_perm_up_small¶

Sets the speed one small step higher (1 % default)

Range: binary
Feedback: Perm up button & Speed slider

[ChannelN]rate_temp_down¶

[PreviewDeckN]rate_temp_down¶

[SamplerN]rate_temp_down¶

Holds the speed one step lower while active

Range: binary
Feedback: Temp down button & Speed slider

[ChannelN]rate_temp_down_small¶

[PreviewDeckN]rate_temp_down_small¶

[SamplerN]rate_temp_down_small¶

Holds the speed one small step lower while active

Range: binary
Feedback: Temp down button & Speed slider

[ChannelN]rate_temp_up¶

[PreviewDeckN]rate_temp_up¶

[SamplerN]rate_temp_up¶

Holds the speed one step higher while active

Range: binary
Feedback: Temp up button & Speed slider

[ChannelN]rate_temp_up_small¶

[PreviewDeckN]rate_temp_up_small¶

[SamplerN]rate_temp_up_small¶

Holds the speed one small step higher while active

Range: binary
Feedback: Temp up button & Speed slider

[ChannelN]rateRange¶

[PreviewDeckN]rateRange¶

[SamplerN]rateRange¶

Sets the range of the Speed slider (0.08 = 8%)

This is a ControlPotMeter control.

Range: 0.0..3.0
Feedback: none, until you move the Speed slider

[ChannelN]rateSearch¶

[PreviewDeckN]rateSearch¶

[SamplerN]rateSearch¶

Seeks forward (positive values) or backward (negative values) at a speed determined by the value

This is a ControlPotMeter control.

Range: -300..300
Feedback: Deck seeks

[ChannelN]rateEngine¶
[PreviewDeckN]rateEngine¶
[SamplerN]rateEngine¶: Actual rate (used in visuals, not for control)

[ChannelN]reloop_andstop¶

[PreviewDeckN]reloop_andstop¶

[SamplerN]reloop_andstop¶

Activate current loop, jump to its loop in point, and stop playback.

Range: binary
Feedback: Loop range in waveform activates or deactivates and play position moves to loop in point.

2.1.0 sürümünde geldi.

[ChannelN]reloop_toggle¶

[PreviewDeckN]reloop_toggle¶

[SamplerN]reloop_toggle¶

Toggles the current loop on or off. If the loop is ahead of the current play position, the track will keep playing normally until it reaches the loop.

Range: binary
Feedback: Loop range in waveform activates or deactivates.

2.1.0 sürümünde geldi.

[ChannelN]repeat¶

[PreviewDeckN]repeat¶

[SamplerN]repeat¶

Enable repeat-mode for the specified deck

Range: binary
Feedback: when track finishes, song loops to beginning

1.9.0 sürümünde geldi.

[ChannelN]reset_key¶

[PreviewDeckN]reset_key¶

[SamplerN]reset_key¶

Resets the key to the original track key.

Range: binary

2.0.0 sürümünde geldi.

[ChannelN]reverse¶

[PreviewDeckN]reverse¶

[SamplerN]reverse¶

Toggles playing the track backwards

Range: binary
Feedback: REV button

[ChannelN]reverseroll¶

[PreviewDeckN]reverseroll¶

[SamplerN]reverseroll¶

Enables reverse and slip mode while held (Censor)

Range: binary
Feedback: REV button

2.0.0 sürümünde geldi.

[ChannelN]scratch2¶

[PreviewDeckN]scratch2¶

[SamplerN]scratch2¶

Affects absolute play speed & direction whether currently playing or not when [ChannelN],scratch2_enabled is active. (multiplicative). Use JavaScript engine.scratch functions to manipulate in controller mappings.

Range: -3.0..3.0
Feedback: Waveform

1.8.0 sürümünde geldi.

[ChannelN]scratch2_enabled¶

[PreviewDeckN]scratch2_enabled¶

[SamplerN]scratch2_enabled¶

Takes over play speed & direction for [ChannelN],scratch2.

Range: binary
Feedback: Waveform

1.8.0 sürümünde geldi.

[ChannelN]slip_enabled¶

[PreviewDeckN]slip_enabled¶

[SamplerN]slip_enabled¶

Toggles slip mode. When active, the playback continues muted in the background during a loop, scratch etc. Once disabled, the audible playback will resume where the track would have been.

Range: binary
Feedback: Slip mode button

1.11.0 sürümünde geldi.

[ChannelN]stars_up¶

[PreviewDeckN]stars_up¶

[SamplerN]stars_up¶

Increase the rating of the currently loaded track (if the skin has star widgets in the decks section).

Range: binary
Feedback: Star count is increased in the deck’s star widget and in the library table.

2.3.0 sürümünde geldi.

[ChannelN]stars_down¶

[PreviewDeckN]stars_down¶

[SamplerN]stars_down¶

Decrease the rating of the currently loaded track (if the skin has star widgets in the decks section).

Range: binary
Feedback: Star count is decreased in the deck’s star widget and in the library table.

2.3.0 sürümünde geldi.

[ChannelN]start¶

[PreviewDeckN]start¶

[SamplerN]start¶

Jump to start of track

Range: binary
Feedback: Track jumps to start

[ChannelN]start_play¶

[PreviewDeckN]start_play¶

[SamplerN]start_play¶

Start playback from the beginning of the deck.

Range: binary
Feedback: Deck plays from beginning

1.10.0 sürümünde geldi.

[ChannelN]start_stop¶

[PreviewDeckN]start_stop¶

[SamplerN]start_stop¶

Seeks a player to the start and then stops it.

Range: binary
Feedback: Deck stops at the beginning.

1.10.0 sürümünde geldi.

[ChannelN]stop¶

[PreviewDeckN]stop¶

[SamplerN]stop¶

Stops a player.

Range: binary
Feedback: Pause Button. Deck pauses at the current position.

1.10.0 sürümünde geldi.

[ChannelN]sync_enabled¶

[PreviewDeckN]sync_enabled¶

[SamplerN]sync_enabled¶

Syncs the tempo and phase (depending on quantize) to that of the other track (if BPM is detected on both). Click and hold for at least one second activates sync lock on that deck.

Range: binary
Feedback: If enabled, the Sync button stays lit and tempo slider snap to the appropriate value. Slider adjustments are linked on all decks that have sync lock enabled.

2.0.0 sürümünde geldi.

[ChannelN]sync_master¶

[PreviewDeckN]sync_master¶

[SamplerN]sync_master¶

Sets deck as leader clock.

Range: binary
Feedback: If enabled, the Sync button stays lit and tempo slider snap to the appropriate value. Slider adjustments are linked on all decks that have sync lock enabled.

2.0.0 sürümünde geldi.

2.3.0 sürümünde değişti: This button just enables sync lock mode (similar to [ChannelN],sync_enabled), it does not actually guarantee the deck will be the sync leader. This will be fixed in a future version.

[ChannelN]sync_mode¶

[PreviewDeckN]sync_mode¶

[SamplerN]sync_mode¶

2.0.0 sürümünde geldi.

Range

Value	Meaning
0	Sync lock disabled for that deck
1	Deck is sync follower
1	Deck is sync leader

[ChannelN]sync_key¶

[PreviewDeckN]sync_key¶

[SamplerN]sync_key¶

Feedback: Key value widget

Match musical key.

2.0.0 sürümünde geldi.

[ChannelN]track_color¶

[PreviewDeckN]track_color¶

[SamplerN]track_color¶

Color of the currently loaded track or -1 if no track is loaded or the track has no color.

Range: 3-Byte RGB color code (or -1)
Feedback: Track color changes in the library view.

2.3.0 sürümünde geldi.

[ChannelN]track_loaded¶

[PreviewDeckN]track_loaded¶

[SamplerN]track_loaded¶

Whether a track is loaded in the specified deck

Range: binary, read-only
Feedback: Waveform and track metadata shown in deck

2.1.0 sürümünde geldi.

[ChannelN]track_samplerate¶

[PreviewDeckN]track_samplerate¶

[SamplerN]track_samplerate¶

Sample rate of the track loaded on the specified deck

Range: absolute value, read-only
Feedback: None

1.9.0 sürümünde geldi.

[ChannelN]track_samples¶

[PreviewDeckN]track_samples¶

[SamplerN]track_samples¶

Number of sound samples in the track loaded on the specified deck

Range: absolute value, read-only
Feedback: None

[ChannelN]volume¶

[PreviewDeckN]volume¶

[SamplerN]volume¶

Adjusts the channel volume fader

This is a ControlPotMeter control.

Range: default
Feedback: Deck volume fader

[ChannelN]mute¶

[PreviewDeckN]mute¶

[SamplerN]mute¶

Mutes the channel

Range: binary
Feedback: Mute button

2.0.0 sürümünde geldi.

[ChannelN]vinylcontrol_enabled¶

[PreviewDeckN]vinylcontrol_enabled¶

[SamplerN]vinylcontrol_enabled¶

Toggles whether a deck is being controlled by digital vinyl.

Range: binary
Feedback: When enabled, a vinyl indication should appear onscreen indicating green for enabled.

1.10.0 sürümünde geldi.

[ChannelN]vinylcontrol_cueing¶

[PreviewDeckN]vinylcontrol_cueing¶

[SamplerN]vinylcontrol_cueing¶

Determines how cue points are treated in vinyl control relative mode.

Range

Value	Meaning
0	Cue points ignored
1	One Cue - If needle is dropped after the cue point, track will seek to that cue point
2	Hot Cue - Track will seek to nearest previous hotcue

1.10.0 sürümünde geldi.

[ChannelN]vinylcontrol_mode¶

[PreviewDeckN]vinylcontrol_mode¶

[SamplerN]vinylcontrol_mode¶

Determines how vinyl control interprets needle information.

Range

Value	Meaning
0	Absolute Mode (track position equals needle position and speed)
1	Relative Mode (track tempo equals needle speed regardless of needle position)
2	Constant Mode (track tempo equals last known-steady tempo regardless of needle input

See Control Mode for details.

Feedback

3-way button indicates status

1.10.0 sürümünde geldi.

[ChannelN]vinylcontrol_status¶

[PreviewDeckN]vinylcontrol_status¶

[SamplerN]vinylcontrol_status¶

Provides visual feedback with regards to vinyl control status.

Range: 0.0-3.0, read-only
Feedback: Off for control disabled, green for control enabled, blinking yellow for when the needle reaches the end of the record, and red for needle skip detected

1.10.0 sürümünde geldi.

[ChannelN]visual_bpm¶

[PreviewDeckN]visual_bpm¶

[SamplerN]visual_bpm¶

BPM to display in the GUI (updated more slowly than the actual BPM).

Range: ?
Feedback: BPM value widget

2.0.0 sürümünde geldi.

[ChannelN]visual_key¶

[PreviewDeckN]visual_key¶

[SamplerN]visual_key¶

Current musical key after pitch shifting to display in the GUI using the notation selected in the preferences

Range: ?
Feedback: Key value widget

2.0.0 sürümünde geldi.

[ChannelN]visual_key_distance¶

[PreviewDeckN]visual_key_distance¶

[SamplerN]visual_key_distance¶

The distance to the nearest key measured in cents

This is a ControlPotMeter control.

Range: -0.5..0.5
Feedback: Key value widget

2.0.0 sürümünde geldi.

[ChannelN]VuMeter¶

[PreviewDeckN]VuMeter¶

[SamplerN]VuMeter¶

Outputs the current instantaneous deck volume

This is a ControlPotMeter control.

Range: default
Feedback: Deck VU meter

[ChannelN]VuMeterL¶

[PreviewDeckN]VuMeterL¶

[SamplerN]VuMeterL¶

Outputs the current instantaneous deck volume for the left channel

This is a ControlPotMeter control.

Range: default
Feedback: Deck VU meter L

[ChannelN]VuMeterR¶

[PreviewDeckN]VuMeterR¶

[SamplerN]VuMeterR¶

Outputs the current instantaneous deck volume for the right channel

This is a ControlPotMeter control.

Range: default
Feedback: Deck VU meter R

[ChannelN]waveform_zoom¶

[PreviewDeckN]waveform_zoom¶

[SamplerN]waveform_zoom¶

Zooms the waveform to look ahead or back as needed.

Range: 1.0 - 10.0
Feedback: Waveform zoom buttons

1.11.0 sürümünde geldi.

[ChannelN]waveform_zoom_up¶

[PreviewDeckN]waveform_zoom_up¶

[SamplerN]waveform_zoom_up¶

Waveform Zoom Out

Range: ?
Feedback: Waveform zoom buttons

1.11.0 sürümünde geldi.

[ChannelN]waveform_zoom_down¶

[PreviewDeckN]waveform_zoom_down¶

[SamplerN]waveform_zoom_down¶

Waveform Zoom In

Range: ?
Feedback: Waveform zoom buttons

1.11.0 sürümünde geldi.

[ChannelN]waveform_zoom_set_default¶

[PreviewDeckN]waveform_zoom_set_default¶

[SamplerN]waveform_zoom_set_default¶

Return to default waveform zoom level

Range: ?
Feedback: Waveform zoom buttons

1.11.0 sürümünde geldi.

[ChannelN]wheel¶

[PreviewDeckN]wheel¶

[SamplerN]wheel¶

Affects relative playback speed and direction persistently (additive offset & must manually be undone).

Range: -3.0..3.0
Feedback: Waveform

Deprecated controls¶

These controls have been deprecated, new controller mappings should use the alternatives.

[ChannelN]beatloop¶

[PreviewDeckN]beatloop¶

[SamplerN]beatloop¶

Setup a loop over the set number of beats.

Range: positive real number
Feedback: A loop is shown over the set number of beats.

2.1.0 sürümünden beri kullanım dışı: Use [ChannelN],beatloop_size and [ChannelN],beatloop_toggle instead.

[ChannelN]reloop_exit¶

[PreviewDeckN]reloop_exit¶

[SamplerN]reloop_exit¶

Toggles the current loop on or off. If the loop is ahead of the current play position, the track will keep playing normally until it reaches the loop.

Range: binary
Feedback: Loop range in waveform activates or deactivates.

2.1.0 sürümünden beri kullanım dışı: Use [ChannelN],reloop_toggle instead.

[ChannelN]jog¶

[PreviewDeckN]jog¶

[SamplerN]jog¶

Affects relative playback speed and direction for short instances (additive & is automatically reset to 0).

Range: -3.0..3.0
Feedback: waveform

?? sürümünden beri kullanım dışı: Use the JavaScript engine.scratch functions instead.

[ChannelN]scratch¶

[PreviewDeckN]scratch¶

[SamplerN]scratch¶

Affects playback speed and direction ([differently whether currently playing or not](https://bugs.launchpad.net/mixxx/+bug/530281)) (multiplicative).

Range: -3.0..3.0
Feedback: Waveform

?? sürümünden beri kullanım dışı: Use the JavaScript engine.scratch functions instead.

[ChannelN]filter¶

[PreviewDeckN]filter¶

[SamplerN]filter¶

Toggles the filter effect.

Range: binary
Feedback: Filter button

2.0.0 sürümünde geldi.

2.0.0 sürümünden beri kullanım dışı: Use [QuickEffectRack1_[ChannelN]_Effect1],enabled instead.

[ChannelN]filterDepth¶

[PreviewDeckN]filterDepth¶

[SamplerN]filterDepth¶

Adjusts the intensity of the filter effect.

Range: default
Feedback: Filter depth knob

2.0.0 sürümünde geldi.

2.0.0 sürümünden beri kullanım dışı: Use [QuickEffectRack1_[ChannelN]],super1 instead.

[ChannelN]filterLow¶

[PreviewDeckN]filterLow¶

[SamplerN]filterLow¶

Adjusts the gain of the low EQ filter.

Range: 0.0..1.0..4.0
Feedback: Low EQ knob

2.0.0 sürümünden beri kullanım dışı: Use [EqualizerRack1_[ChannelN]_Effect1],parameter1 instead.

[ChannelN]filterLowKill¶

[PreviewDeckN]filterLowKill¶

[SamplerN]filterLowKill¶

Holds the gain of the low EQ to -inf while active

Range: binary
Feedback: Low EQ kill switch

2.0.0 sürümünden beri kullanım dışı: Use [EqualizerRack1_[ChannelI]_Effect1],button_parameter1 instead.

[ChannelN]filterMid¶

[PreviewDeckN]filterMid¶

[SamplerN]filterMid¶

Adjusts the gain of the mid EQ filter..

Range: 0.0..1.0..4.0
Feedback: Mid EQ knob

2.0.0 sürümünden beri kullanım dışı: Use [EqualizerRack1_[ChannelI]_Effect1],parameter2 instead.

[ChannelN]filterMidKill¶

[PreviewDeckN]filterMidKill¶

[SamplerN]filterMidKill¶

Holds the gain of the mid EQ to -inf while active.

Range: binary
Feedback: Mid EQ kill switch

2.0.0 sürümünden beri kullanım dışı: Use [EqualizerRack1_[ChannelI]_Effect1],button_parameter2 instead.

[ChannelN]filterHigh¶

[PreviewDeckN]filterHigh¶

[SamplerN]filterHigh¶

Adjusts the gain of the high EQ filter.

Range: 0.0..1.0..4.0
Feedback: High EQ knob

2.0.0 sürümünden beri kullanım dışı: Use [EqualizerRack1_[ChannelI]_Effect1],parameter3 instead.

[ChannelN]filterHighKill¶

[PreviewDeckN]filterHighKill¶

[SamplerN]filterHighKill¶

Holds the gain of the high EQ to -inf while active.

Range: binary
Feedback: High EQ kill switch

2.0.0 sürümünden beri kullanım dışı: Use [EqualizerRack1_[ChannelI]_Effect1],button_parameter3 instead.

[ChannelN]beatloop_X¶

[PreviewDeckN]beatloop_X¶

[SamplerN]beatloop_X¶

Setup a loop over X beats. A control exists for X = 0.03125, 0.0625, 0.125, 0.25, 0.5, 1, 2, 4, 8, 16, 32, 64

Range: toggle
Feedback: A loop is shown over X beats.

1.10.0 sürümünde geldi.

2.0.0 sürümünden beri kullanım dışı: Use [ChannelN],beatloop_X_activate instead.

Global Sampler controls¶

These controls can be used to control all samplers.

[Samplers]show_samplers¶

Range: binary
Feedback: Shows Sampler bank(s)

[Sampler]SaveSamplerBank¶

Save sampler configuration. Make currently loaded tracks in samplers instantly available at a later point.

Range: binary
Feedback: Opens file dialog. Configuration file can be named and saved.

[Sampler]LoadSamplerBank¶

Load saved sampler configuration file and add tracks to the available samplers.

Range: binary
Feedback: Opens file dialog. Select configuration file.

Microphones and Auxiliary Channels¶

In contrast to decks, preview decks and samplers, microphones and auxiliary channels are input channels. You can map audio interface’s inputs to mixxx’s auxiliary input channels and connect external audio source to it (cellphone, mp3 player). Then you can use your MIDI controller to control its volume and some other parameters (orientation, gain, volume), apply effects and use the prelisten function.

Not

Although the first auxiliary group is named [Auxiliary1], the group for the first microphone is just called [Microphone], not [Microphone1].

[MicrophoneN]enabled¶

[AuxiliaryN]enabled¶

1 if a channel input is enabled, 0 if not.

Range: binary
Feedback: Microphone is enabled.

1.10.0 sürümünde geldi.

2.0.0 sürümünden beri kullanım dışı: Use [MicrophoneN],input_configured instead.

[MicrophoneN]input_configured¶

[AuxiliaryN]input_configured¶

1 if there is input is configured for this channel, 0 if not.

Range: binary, read-only
Feedback: Configured channel in the sound preferences.

[MicrophoneN]master¶

[AuxiliaryN]master¶

Hold value at 1 to mix channel input into the master output. For [MicrophoneN] use [MicrophoneN],talkover instead. Note that [AuxiliaryN] also take [AuxiliaryN],orientation into account.

Range: binary
Feedback: Auxiliary: Play button Microphone: N/A

[AuxiliaryN]orientation¶

Set channel orientation for the crossfader.

Range

Value	Meaning
0	Left side of crossfader
1	Center (not affected by crossfader)
2	Right side of crossfader

Feedback

None

1.10.0 sürümünde geldi.

[MicrophoneN]orientation¶: 1.10.0 sürümünde geldi.

1.10.0 sürümünden beri kullanım dışı: The control is not processed in the Mixer, which is also why there are no orientation controls for Microphones in the GUI.

[MicrophoneN]PeakIndicator¶

[AuxiliaryN]PeakIndicator¶

Indicates when the signal is clipping (too loud for the hardware and is being distorted)

This is a ControlPotMeter control.

Range: binary
Feedback: Microphone Clip light

1.10.0 sürümünde geldi.

[MicrophoneN]PeakIndicatorL¶

[AuxiliaryN]PeakIndicatorL¶

Indicates when the signal is clipping (too loud for the hardware and is being distorted) for the left channel

This is a ControlPotMeter control.

Range: binary
Feedback: Clip light (left)

2.0.0 sürümünde geldi.

[MicrophoneN]PeakIndicatorR¶

[AuxiliaryN]PeakIndicatorR¶

Indicates when the signal is clipping (too loud for the hardware and is being distorted) for the right channel

This is a ControlPotMeter control.

Range: binary
Feedback: Clip light (right)

2.0.0 sürümünde geldi.

[MicrophoneN]pfl¶

[AuxiliaryN]pfl¶

Toggles headphone cueing (PFL).

Range: binary
Feedback: Headphone button

[MicrophoneN]talkover¶

Hold value at 1 to mix channel input into the master output.

Range: binary
Feedback: Talk button

1.10.0 sürümünde geldi.

[MicrophoneN]volume¶

[AuxiliaryN]volume¶

Adjusts the channel volume fader

This is a ControlPotMeter control.

Range: default
Feedback: Microphone volume fader changes

1.10.0 sürümünde geldi.

[MicrophoneN]pregain¶

[AuxiliaryN]pregain¶

Adjusts the gain of the input

This is a ControlPotMeter control.

Range: 0.0..1.0..4.0
Feedback: Microphone gain knob

[MicrophoneN]mute¶

[AuxiliaryN]mute¶

Mutes the channel

Range: binary
Feedback: Mute button

2.0.0 sürümünde geldi.

[MicrophoneN]VuMeter¶

[AuxiliaryN]VuMeter¶

Outputs the current instantaneous channel volume

This is a ControlPotMeter control.

Range: default
Feedback: Microphone VU meter changes

1.10.0 sürümünde geldi.

[MicrophoneN]VuMeterL¶

[AuxiliaryN]VuMeterL¶

Outputs the current instantaneous deck volume for the left channel

This is a ControlPotMeter control.

Range: default
Feedback: Deck VU meter L

2.0.0 sürümünde geldi.

[MicrophoneN]VuMeterR¶

[AuxiliaryN]VuMeterR¶

Outputs the current instantaneous deck volume for the right channel

This is a ControlPotMeter control.

Range: default
Feedback: Deck VU meter R

2.0.0 sürümünde geldi.

The `[VinylControl]` group¶

The [VinylControl] group can toggle the vinyl control feature.

[VinylControl]Toggle¶

Moves control by a vinyl control signal from one deck to another if using the single deck vinyl control (VC) feature.

Range: binary
Feedback: If VC isn’t enabled on any decks, enable it on the first one we’re receiving samples for. If VC is enabled on a single (exclusive) deck, and another deck is setup to receive samples, disable it on the former deck and enable it on the next eligible deck (ordered by deck number). If VC is enabled on multiple decks, don’t do anything.

1.10.0 sürümünde geldi.

[VinylControl]show_vinylcontrol¶

Toggle the vinyl control section in skins.

Range: binary
Feedback: Vinyl controls are shown

1.10.0 sürümünde geldi.

[VinylControl]gain¶

Allows to amplify the “phono” level of attached turntables to “line” level. This is equivalent to setting the turntable boost in Options ‣ Preferences ‣ Vinyl Control

Range: binary
Feedback: position of Boost slider in Options ‣ Preferences ‣ Vinyl Control (is not updated while viewing this Preferences page)

1.10.0 sürümünde geldi.

The `[Recording]` controls¶

The controls in the [Recording] group can be used to query and control the recording of your mix.

[Recording]toggle_recording¶

Turns recording on or off.

Range: binary
Feedback: Recording icon

[Recording]status¶

Indicates whether Mixxx is currently recording.

Range

Value	Meaning
0	Recording Stopped
1	Initialize Recording
2	Recording Active

Feedback

Recording icon

AutoDJ controls¶

The [AutoDJ] controls allow interacting with AutoDJ.

[AutoDJ]enabled¶

Turns Auto DJ on or off.

Range: binary
Feedback: AutoDJ button

1.11.0 sürümünde geldi.

[AutoDJ]shuffle_playlist¶

Shuffles the content of the Auto DJ playlist.

Range: binary
Feedback: Order of tracks in the AutoDJ playlist changes.

1.11.0 sürümünde geldi.

[AutoDJ]skip_next¶

Skips the next track in the Auto DJ playlist.

Range: binary
Feedback: Skipped track is removed from the AutoDJ playlist.

1.11.0 sürümünde geldi.

[AutoDJ]fade_now¶

Triggers the transition to the next track.

Range: binary
Feedback: Crossfader slider moves to the other side.

1.11.0 sürümünde geldi.

[AutoDJ]add_random_track¶

Adds a random track to the Auto DJ queue.

Range: binary
Feedback: Track is added to AutoDJ queue.

2.4.0 sürümünde geldi.

The `[Library]` controls¶

The controls in the [Library] group can be used to navigate the library. Note that [Library],MoveUp and other Move and Scroll controls emulate keypresses and therefore require the Mixxx window to be focused.

[Library]MoveUp¶

Equivalent to pressing the Up key on the keyboard

Range: Binary
Feedback: Currently selected item changes

2.1.0 sürümünde geldi.

[Library]MoveDown¶

Equivalent to pressing the Down key on the keyboard

Range: Binary
Feedback: Currently selected item changes

2.1.0 sürümünde geldi.

[Library]MoveVertical¶

Move the specified number of locations up or down. Intended to be mapped to an encoder knob.

Range: Relative (positive values move down, negative values move up)
Feedback: Currently selected item changes

2.1.0 sürümünde geldi.

[Library]ScrollUp¶

Equivalent to pressing the PageUp key on the keyboard

Range: Binary
Feedback: Currently selected item changes

2.1.0 sürümünde geldi.

[Library]ScrollDown¶

Equivalent to pressing the PageDown key on the keyboard

Range: Binary
Feedback: Currently selected item changes

2.1.0 sürümünde geldi.

[Library]ScrollVertical¶

Scroll the specified number of pages up or down. Intended to be mapped to an encoder knob.

Range: Relative (positive values move down, negative values move up)
Feedback: Currently selected item changes

2.1.0 sürümünde geldi.

[Library]MoveLeft¶

Equivalent to pressing the Left key on the keyboard

Range: Binary
Feedback: Currently selected item changes

2.1.0 sürümünde geldi.

[Library]MoveRight¶

Equivalent to pressing the Right key on the keyboard

Range: Binary
Feedback: Currently selected item changes

2.1.0 sürümünde geldi.

[Library]MoveHorizontal¶

Move the specified number of locations left or right. Intended to be mapped to an encoder knob.

Range: Relative (positive values move right, negative values move left)
Feedback: Currently selected item changes

2.1.0 sürümünde geldi.

[Library]MoveFocusForward¶

Equivalent to pressing the Tab key on the keyboard

Range: Binary
Feedback: Currently focused pane changes

2.1.0 sürümünde geldi.

[Library]MoveFocusBackward¶

Equivalent to pressing the Shift + Tab key on the keyboard

Range: Binary
Feedback: Currently focused pane changes

2.1.0 sürümünde geldi.

[Library]MoveFocus¶

Move focus the specified number of panes forward or backwards. Intended to be mapped to an encoder knob.

Range: Relative (positive values move forward, negative values move backward)
Feedback: Currently focused pane changes

2.1.0 sürümünde geldi.

[Library]GoToItem¶

Equivalent to double clicking the currently selected item

Range: Binary
Feedback: Context dependent

2.1.0 sürümünde geldi.

[Library]AutoDjAddBottom¶

[Playlist]AutoDjAddBottom¶

Add selected track(s) to Auto DJ Queue (bottom).

Range: Binary
Feedback: Append track(s) to Auto DJ playlist

2.0.0 sürümünde geldi.

[Library]AutoDjAddTop¶

[Playlist]AutoDjAddTop¶

Add selected track(s) to Auto DJ Queue (top).

Range: Binary
Feedback: Prepend track(s) to Auto DJ playlist

2.0.0 sürümünde geldi.

[Library]show_coverart¶

Toggle the Cover Art in Library

Range: Binary

[Library]font_size_increment¶

Increase the size of the library font. If the row height is smaller than the font-size the larger of the two is used.

Range: Binary
Feedback: Library view

2.0.0 sürümünde geldi.

[Library]font_size_decrement¶

Decrease the size of the library font

2.0.0 sürümünde geldi.

Range: Binary
Feedback: Library view

[Library]font_size_knob¶

Increase or decrease the size of the library font

2.0.0 sürümünde geldi.

Range: Relative
Feedback: Library view

[Library]sort_column¶

Indicates the sorting column the track table

Range

Value	Description	Library	Playlist	Crate	Browse
1	Artist	X	X	X	X
2	Title	X	X	X	X
3	Album	X	X	X	X
4	Albumartist	X	X	X	X
5	Year	X	X	X	X
6	Genre	X	X	X	X
7	Composer	X	X	X	X
8	Grouping	X	X	X	X
9	Tracknumber	X	X	X	X
10	Filetype	X	X	X	X
11	Native Location	X	X	X	X
12	Comment	X	X	X	X
13	Duration	X	X	X	X
14	Bitrate	X	X	X	X
15	BPM	X	X	X	X
16	ReplayGain	X	X	X	X
17	Datetime Added	X	X	X	X
18	Times Played	X	X	X	X
19	Rating	X	X	X	X
20	Key	X	X	X	X
21	Preview	X	X	X	X
22	Coverart	X	X	X
23	Position		X
24	Playlist ID		X
25	Location		X
26	Filename				X
27	File Modified Time				X
28	File Creation Time				X
29	Sample Rate
30	Track Color	X	X	X

Feedback

Sorting indicator in the column headers of the track table

2.3.0 sürümünde geldi.

[Library]sort_column_toggle¶

Equivalent to clicking on column headers. A new value sets [Library],sort_column to that value and [Library],sort_order to 0, setting the same value again will toggle [Library],sort_order.

Range: Same as for [Library],sort_column or value 0 for sorting according the current column with the cursor on it
Feedback: Sorting indicator in the column headers of the track table

2.3.0 sürümünde geldi.

[Library]sort_order¶

Indicate the sort order of the track tables.

Range: Binary (0 for ascending, 1 for descending)
Feedback: Sorting indicator in the column headers of the track table

2.3.0 sürümünde geldi.

[Library]track_color_prev¶

Set color of selected track to previous color in palette.

Range: Binary
Feedback: Track color changes in the library view.

2.3.0 sürümünde geldi.

[Library]track_color_next¶

Set color of selected track to next color in palette.

Range: Binary
Feedback: Track color changes in the library view.

2.3.0 sürümünde geldi.

The `[Playlist]` controls¶

[Playlist] controls allow navigating the sidebar and tracks table directly without considering the currently focused widget. This is helpful when another application’s window is focused. This group is going to be deprecated at some point, with its controls added to [Library] above.

Ayrıca bakınız

See bug #1772184 for the current status.

[Playlist]SelectPlaylist¶

Scrolls the given number of items (view, playlist, crate, etc.) in the side pane (can be negative for reverse direction).

Range: relative value
Feedback: Library sidebar highlight

[Playlist]SelectTrackKnob¶

Scrolls the given number of tracks in the track table (can be negative for reverse direction).

Range: relative value
Feedback: Library track table highlight

[Playlist]LoadSelectedIntoFirstStopped¶: Loads the currently highlighted song into the first stopped deck

2.1.0 sürümünden beri kullanım dışı: Use [Library],GoToItem instead.

[Playlist]SelectNextPlaylist¶: Switches to the next view (Library, Queue, etc.)

2.1.0 sürümünden beri kullanım dışı: Use [Library],MoveDown instead.

[Playlist]SelectPrevPlaylist¶: Switches to the previous view (Library, Queue, etc.)

2.1.0 sürümünden beri kullanım dışı: Use [Library],MoveUp instead.

[Playlist]ToggleSelectedSidebarItem¶: Toggles (expands/collapses) the currently selected sidebar item.

1.11.0 sürümünde geldi.

2.1.0 sürümünden beri kullanım dışı: Use [Library],GoToItem instead.

[Playlist]SelectNextTrack¶: Scrolls to the next track in the track table.

2.1.0 sürümünden beri kullanım dışı: Use [Library],MoveDown instead.

[Playlist]SelectPrevTrack¶: Scrolls to the previous track in the track table.

2.1.0 sürümünden beri kullanım dışı: Use [Library],MoveUp instead.

The `[Controls]` controls¶

The [Controls] group contains controls that didn’t fit in any other group.

[Controls]touch_shift¶

Once enabled, all touch tab events are interpreted as right click. This control has been added to provide touchscreen compatibility in 2.0 and might be replaced by a general modifier solution in the future.

Range: binary
Feedback: All Widgets

2.0.0 sürümünde geldi.

[Controls]AutoHotcueColors¶

If enabled, colors will be assigned to newly created hotcues automatically.

Range: binary
Feedback: None

2.3.0 sürümünde geldi.

The Effects Framework¶

In the list below,

EffectRack1 leaves room for future expansion to multiple EffectRacks.

N ranges from 1 to [EffectRack1],num_effectunits, inclusive.

M ranges from 1 to [EffectRack1_EffectUnitN],num_effectslots, inclusive. (For a given value of N)

K ranges from 1 to [EffectRack1_EffectUnitN_EffectM],num_parameters, inclusive. (For given values of N and M)

I ranges from 1 to [Master],num_decks, inclusive.

J ranges from 1 to [Master],num_samplers, inclusive.

2.0.0 sürümünde geldi.

Linking Values¶

Effect parameters can be linked to the effect’s metaknob. This linkage can be user-controlled by changing the link_type and the link_inverse control of the parameter. The default link type is loaded from the effect parameter’s manifest’s linkHint property.

Link Type	Integer Value	Interpretation
None	0	Not controlled by the metaknob
Linked	1	Controlled by the metaknob as it is
Linked Left	2	Controlled by the left side of the metaknob
Linked Right	3	Controlled by the right side of the metaknob
Linked Left Right	4	Controlled by both sides of the metaknob

Link Inverse	Integer Value	Interpretation
Normal	0	Linked in equal relation
Inverse	1	Linked in an inverse relation.

EQs and Filters¶

Equalizers and filters are special effects units. The EQs are controlled by [EqualizerRack1_[ChannelI]_Effect1] and the filter knob is controlled by [QuickEffectRack1_[ChannelI]],super1 and [QuickEffectRack1_[ChannelI]_Effect1],enabled. Users can choose between several options for the effects loaded in these racks in the Equalizers section of the Preferences window.

Controls¶

[EffectRack1]show¶

Show the Effect Rack

Range: binary

[EffectRack1]num_effectunits¶

[EqualizerRack1]num_effectunits¶

[QuickEffectRack1]num_effectunits¶

The number of EffectUnits in this rack

Range: integer, read-only

[EffectRack1]clear¶

[EqualizerRack1]clear¶

[QuickEffectRack1]clear¶

Clear the Effect Rack

Range: binary

[EffectRack1_EffectUnitN]chain_selector¶

[EqualizerRack1_[ChannelI]]chain_selector¶

[QuickEffectRack1_[ChannelI]]chain_selector¶

Select EffectChain preset. > 0 goes one forward; < 0 goes one backward.

Range: +1/-1

[EffectRack1_EffectUnitN]clear¶

[EqualizerRack1_[ChannelI]]clear¶

[QuickEffectRack1_[ChannelI]]clear¶

Clear the currently loaded EffectChain in this EffectUnit.

Range: binary

[EffectRack1_EffectUnitN]enabled¶

[EqualizerRack1_[ChannelI]]enabled¶

[QuickEffectRack1_[ChannelI]]enabled¶

If true, the EffectChain in this EffectUnit will be processed. Meant to allow the user a quick toggle for the effect unit.

Range: binary, default true

[EffectRack1_EffectUnitN]focused_effect¶

[EqualizerRack1_[ChannelI]]focused_effect¶

[QuickEffectRack1_[ChannelI]]focused_effect¶

0 indicates no effect is focused; > 0 indicates the index of the focused effect. Focusing an effect only does something if a controller mapping changes how it behaves when an effect is focused.

Range: 0..num_effects

[EffectRack1_EffectUnitN]group_[ChannelI]_enable¶

[EqualizerRack1_[ChannelI]]group_[ChannelI]_enable¶

[QuickEffectRack1_[ChannelI]]group_[ChannelI]_enable¶

Whether or not this EffectChain applies to Deck I

Range: binary

[EffectRack1_EffectUnitN]group_[Headphone]_enable¶

Whether or not this EffectChain applies to the Headphone output

Range: binary

[EffectRack1_EffectUnitN]group_[Master]_enable¶

Whether or not this EffectChain applies to the Master output

Range: binary

[EffectRack1_EffectUnitN]group_[SamplerJ]_enable¶

Whether or not this EffectChain applies to Sampler J

Range: binary

[EffectRack1_EffectUnitN]loaded¶

[EqualizerRack1_[ChannelI]]loaded¶

[QuickEffectRack1_[ChannelI]]loaded¶

Whether an EffectChain is loaded into the EffectUnit

Range: binary, read-only

[EffectRack1_EffectUnitN]mix¶

[EqualizerRack1_[ChannelI]]mix¶

[QuickEffectRack1_[ChannelI]]mix¶

The dry/wet mixing ratio for this EffectChain with the EngineChannels it is mixed with

This is a ControlPotMeter control.

Range: 0.0..1.0

[EffectRack1_EffectUnitN]next_chain¶

[EqualizerRack1_[ChannelI]]next_chain¶

[QuickEffectRack1_[ChannelI]]next_chain¶

Cycle to the next EffectChain preset after the currently loaded preset.

Range: binary

[EffectRack1_EffectUnitN]num_effects¶

[EqualizerRack1_[ChannelI]]num_effects¶

[QuickEffectRack1_[ChannelI]]num_effects¶

The number of Effects that this EffectChain has

Range: integer, read-only

[EffectRack1_EffectUnitN]num_effectslots¶

[EqualizerRack1_[ChannelI]]num_effectslots¶

[QuickEffectRack1_[ChannelI]]num_effectslots¶

The number of effect slots available in this EffectUnit.

Range: integer, read-only

[EffectRack1_EffectUnitN]prev_chain¶

[EqualizerRack1_[ChannelI]]prev_chain¶

[QuickEffectRack1_[ChannelI]]prev_chain¶

Cycle to the previous EffectChain preset before the currently loaded preset.

Range: binary

[EffectRack1_EffectUnitN]show_focus¶

[EqualizerRack1_[ChannelI]]show_focus¶

[QuickEffectRack1_[ChannelI]]show_focus¶

Whether to show focus buttons and draw a border around the focused effect in skins. This should not be manipulated by skins; it should only be changed by controller mappings.

Range: binary

[EffectRack1_EffectUnitN]show_parameters¶

[EqualizerRack1_[ChannelI]]show_parameters¶

[QuickEffectRack1_[ChannelI]]show_parameters¶

Range: binary

Whether to show all the parameters of each effect in skins or only show metaknobs.

[EffectRack1_EffectUnitN]super1¶

[EqualizerRack1_[ChannelI]]super1¶

[QuickEffectRack1_[ChannelI]]super1¶

The EffectChain superknob. Moves the metaknobs for each effect in the chain.

This is a ControlPotMeter control.

Range: 0.0..1.0

[EffectRack1_EffectUnitN_EffectM]clear¶

[EqualizerRack1_[ChannelI]_Effect1]clear¶

[QuickEffectRack1_[ChannelI]_Effect1]clear¶

Clear the currently loaded Effect in this Effect slot from the EffectUnit.

Range: binary

[EffectRack1_EffectUnitN_EffectM]effect_selector¶

[EqualizerRack1_[ChannelI]_Effect1]effect_selector¶

[QuickEffectRack1_[ChannelI]_Effect1]effect_selector¶

Select Effect – >0 goes one forward, <0 goes one backward.

Range: +1/-1

[EffectRack1_EffectUnitN_EffectM]enabled¶

[EqualizerRack1_[ChannelI]_Effect1]enabled¶

[QuickEffectRack1_[ChannelI]_Effect1]enabled¶

If true, the effect in this slot will be processed. Meant to allow the user a quick toggle for this effect.

Range: binary, default true

[EffectRack1_EffectUnitN_EffectM]loaded¶

[EqualizerRack1_[ChannelI]_Effect1]loaded¶

[QuickEffectRack1_[ChannelI]_Effect1]loaded¶

Whether an Effect is loaded into this EffectSlot

Range: binary, read-only

[EffectRack1_EffectUnitN_EffectM]next_effect¶

[EqualizerRack1_[ChannelI]_Effect1]next_effect¶

[QuickEffectRack1_[ChannelI]_Effect1]next_effect¶

Cycle to the next effect after the currently loaded effect.

Range: binary

[EffectRack1_EffectUnitN_EffectM]num_parameters¶

[EqualizerRack1_[ChannelI]_Effect1]num_parameters¶

[QuickEffectRack1_[ChannelI]_Effect1]num_parameters¶

The number of parameters the currently loaded effect has.

Range: integer, read-only, 0 if no effect is loaded

[EffectRack1_EffectUnitN_EffectM]num_parameterslots¶

[EqualizerRack1_[ChannelI]_Effect1]num_parameterslots¶

[QuickEffectRack1_[ChannelI]_Effect1]num_parameterslots¶

The number of parameter slots available.

Range: integer, read-only

[EffectRack1_EffectUnitN_EffectM]num_button_parameters¶

[EqualizerRack1_[ChannelI]_Effect1]num_button_parameters¶

[QuickEffectRack1_[ChannelI]_Effect1]num_button_parameters¶

The number of button parameters the currently loaded effect has.

Range: integer, read-only, 0 if no effect is loaded

[EffectRack1_EffectUnitN_EffectM]num_button_parameterslots¶

[EqualizerRack1_[ChannelI]_Effect1]num_button_parameterslots¶

[QuickEffectRack1_[ChannelI]_Effect1]num_button_parameterslots¶

The number of button parameter slots available.

Range: integer, read-only

[EffectRack1_EffectUnitN_EffectM]meta¶

[EqualizerRack1_[ChannelI]_Effect1]meta¶

[QuickEffectRack1_[ChannelI]_Effect1]meta¶

Controls the parameters that are linked to the metaknob.

This is a ControlPotMeter control.

Range: 0..1

[EffectRack1_EffectUnitN_EffectM]prev_effect¶

[EqualizerRack1_[ChannelI]_Effect1]prev_effect¶

[QuickEffectRack1_[ChannelI]_Effect1]prev_effect¶

Cycle to the previous effect before the currently loaded effect.

Range: binary

[EffectRack1_EffectUnitN_EffectM]parameterK¶

[EqualizerRack1_[ChannelI]_Effect1]parameterK¶

[QuickEffectRack1_[ChannelI]_Effect1]parameterK¶

The scaled value of the Kth parameter. See the Parameter Values section for more information.

This is a ControlPotMeter control.

Range: double

[EffectRack1_EffectUnitN_EffectM]parameterK_link_inverse¶

[EqualizerRack1_[ChannelI]_Effect1]parameterK_link_inverse¶

[QuickEffectRack1_[ChannelI]_Effect1]parameterK_link_inverse¶

The link direction of the Kth parameter to the effect’s metaknob.

Range: bool

[EffectRack1_EffectUnitN_EffectM]parameterK_link_type¶

[EqualizerRack1_[ChannelI]_Effect1]parameterK_link_type¶

[QuickEffectRack1_[ChannelI]_Effect1]parameterK_link_type¶

The link type of the Kth parameter to the effects’s metaknob.

Range: enum

[EffectRack1_EffectUnitN_EffectM]parameterK_loaded¶

[EqualizerRack1_[ChannelI]_Effect1]parameterK_loaded¶

[QuickEffectRack1_[ChannelI]_Effect1]parameterK_loaded¶

Whether or not the Kth parameter slot has an effect parameter loaded into it.

Range: binary, read-only

[EffectRack1_EffectUnitN_EffectM]parameterK_type¶

[EqualizerRack1_[ChannelI]_Effect1]parameterK_type¶

[QuickEffectRack1_[ChannelI]_Effect1]parameterK_type¶

The type of the Kth parameter value. See the Parameter Value Types table.

Range: integer, read-only

[EffectRack1_EffectUnitN_EffectM]button_parameterK¶

[EqualizerRack1_[ChannelI]_Effect1]button_parameterK¶

[QuickEffectRack1_[ChannelI]_Effect1]button_parameterK¶

The value of the Kth parameter. See the Parameter Values section for more information.

Range: double

[EffectRack1_EffectUnitN_EffectM]button_parameterK_loaded¶

[EqualizerRack1_[ChannelI]_Effect1]button_parameterK_loaded¶

[QuickEffectRack1_[ChannelI]_Effect1]button_parameterK_loaded¶

Whether or not the Kth parameter slot has an effect parameter loaded into it.

Range: binary, read-only

[EffectRack1_EffectUnitN_EffectM]button_parameterK_type¶

[EqualizerRack1_[ChannelI]_Effect1]button_parameterK_type¶

[QuickEffectRack1_[ChannelI]_Effect1]button_parameterK_type¶

The type of the Kth parameter value. See the Parameter Value Types table.

Range: integer, read-only

Removed controls¶

These controls have been removed from Mixxx. Skins and controller mappings that attempt to use them will not work correctly.

[ChannelN]flanger¶: Toggles the flanger effect.

2.0.0 sürümünden beri kullanım dışı: This control has been removed without a direct replacement. Use the effects framework instead.

[ChannelN]Hercules1¶
[ChannelN]Hercules2¶
[ChannelN]Hercules3¶
[ChannelN]Hercules4¶: ?? sürümünden beri kullanım dışı: This control has been removed.

[ChannelN]NextTask¶: ?? sürümünden beri kullanım dışı: This control has been removed.

[ChannelN]NextTrack¶: ?? sürümünden beri kullanım dışı: This control has been removed.

[ChannelN]PrevTask¶: ?? sürümünden beri kullanım dışı: This control has been removed.

[ChannelN]PrevTrack¶: ?? sürümünden beri kullanım dışı: This control has been removed.

[ChannelN]transform¶: ?? sürümünden beri kullanım dışı: This control has been removed.

[Flanger]lfoDepth¶: Adjusts the intensity of the flange effect

2.0.0 sürümünden beri kullanım dışı: This control has been removed without a direct replacement. Use the effects framework instead.

[Flanger]lfoDelay¶: Adjusts the phase delay of the flange effect in microseconds

2.0.0 sürümünden beri kullanım dışı: This control has been removed without a direct replacement. Use the effects framework instead.

[Flanger]lfoPeriod¶: Adjusts the wavelength of the flange effect in microseconds

2.0.0 sürümünden beri kullanım dışı: This control has been removed without a direct replacement. Use the effects framework instead.

14.2. Making a Custom Keyboard Mapping¶

The default keyboard mappings are defined in a text file which can be found at the following location:

Linux: /usr/local/share/mixxx/keyboard/en_US.kbd.cfg
macOS: /Applications/Mixxx.app/Contents/Resources/keyboard/en_US.kbd.cfg
Windows: <Mixxx installation directory>\keyboard\en_US.kbd.cfg

Depending on your system’s language settings, Mixxx might use a different file as default, e.g. de_DE.kbd.cfg for German or es_ES.kbd.cfg for Spanish.

It is not recommended that you modify the system-wide keyboard mapping file because all your changes may be lost if you uninstall or upgrade Mixxx. Instead, copy the default mapping file to the following location:

Linux: ~/.mixxx/Custom.kbd.cfg
macOS: ~/Library/Application\ Support/Mixxx/Custom.kbd.cfg
Windows: %LOCALAPPDATA%\Mixxx\Custom.kbd.cfg

Then edit this file and save the changes. On the next startup, Mixxx will check if Custom.kbd.cfg is present and load that file instead of the default mapping file. This has the advantage that you can always revert back to the default mapping by deleting Custom.kbd.cfg.

For a list of controls that can be used in a keyboard mapping, see https://github.com/mixxxdj/mixxx/wiki/mixxxcontrols.

You can download and share custom keyboard mappings in the Mixxx User customizations forums.

14.3. Additional Effects via external Mixer Mode¶

Mixxx comes with a set of native effects. Additionally, using the external mixer mode you can route each deck directly to 3rd party effect hosts.

The following examples are only intended to encourage experimentation, they are not definitive guidance.

Effects via AU Lab on macOS¶

The Au Lab routing for external effects on macOS¶

On macOS there is a simple and free way to give Mixxx access to the collection of AU/VST/MAS plugins that are installed on your system.

Install the free Soundflower, a system extension for inter-application audio routing.
Install the free digital audio mixing application AU Lab.

İpucu

macOS 10.15 (Catalina) introduces additional restrictions on running non-Apple software. Make sure to grant permission in System Preferences –> Security & Privacy –> Microphone –> AU Lab.

Alternatively, try Blackhole, a modern virtual audio driver that allows applications to pass audio to other applications with zero additional latency, and Hosting AU, a free micro-sized DAW that hosts Audio Unit instruments and effect plugins.

In Mixxx

Go to Preferences ‣ Sound Hardware‣ Output
Select for Deck 1 the Soundflower 16 device with Channel 1-2
Select for Deck 2 the Soundflower 16 device with Channel 3-4
Click the Apply button

In AU Lab

Click on the + button to create a new configuration
Add 2 stereo input tracks in the Audio Input Tab
Add 2 stereo output tracks in the Audio Output Tab
Click OK
Change the audio input device to Soundflower 16
Change the audio output device for example to Built-in Output
Click Create document
In the Output 1 channel, select an effect from the drop-down menu, for example Apple ‣ AUCompressor

The effect should now react if you play a track in Mixxx.

Effects via JACK Rack on GNU/Linux¶

The Jack routing for external effects on GNU/Linux¶

Use Jack to route each deck directly through JACK Rack effect racks, or for more control you can use Ardour (or another DAW) using sends for effects. This gives Mixxx access to the extensive collection of LADSPA plugins.

Make sure the correct multichannel audio interface has been selected in Jack (Jack settings visible bottom left). Note that Mixxx possibly labels its Jack ports as Portaudio.

14.4. Deleting Your Library¶

The library file is stored in the following places depending on your operating system:

Windows

The Mixxx library is stored in the %USERPROFILE%\Local Settings\Application Data\Mixxx\ folder. To delete your library on Windows, delete the mixxxdb.sqlite file in this folder.

macOS

The Mixxx library is stored in the Library/Application Support/Mixxx folder in your home directory. To delete your library on macOS type the following command into a terminal:

rm ~/Library/Application\ Support/Mixxx/mixxxdb.sqlite

GNU/Linux

The Mixxx library is stored in the .mixxx folder in your home directory. To delete your library on GNU/Linux type the following command into a terminal:

rm ~/.mixxx/mixxxdb.sqlite

Uyarı

Deleting your library will lose all of your metadata. This includes saved hotcues, loops, comments, ratings, and other library related metadata. Only delete your library if you are fine with losing these.

14. Advanced Topics¶

14.1. Adding support for your MIDI/HID Controller¶

Controller Wizard¶

MIDI Scripting¶

Mixxx Controls¶

ControlPotMeter controls¶

The [Master] group¶

Decks, Preview Decks and Samplers¶

Deprecated controls¶

Global Sampler controls¶

Microphones and Auxiliary Channels¶

The [VinylControl] group¶

The [Recording] controls¶

AutoDJ controls¶

The [Library] controls¶

The [Playlist] controls¶

The [Controls] controls¶

The Effects Framework¶

Linking Values¶

EQs and Filters¶

Controls¶

Removed controls¶

14.2. Making a Custom Keyboard Mapping¶

14.3. Additional Effects via external Mixer Mode¶

Effects via AU Lab on macOS¶

Effects via JACK Rack on GNU/Linux¶

14.4. Deleting Your Library¶

The `[Master]` group¶

The `[VinylControl]` group¶

The `[Recording]` controls¶

The `[Library]` controls¶

The `[Playlist]` controls¶

The `[Controls]` controls¶
